The Express 280 anchor bolt pattern appears below.
Drainage
Ensure any site slopes, walls, or fencing do not trap water around the installation site.
WARNING: Exposing the ChargePoint charging components to over 406 mm (16 in) of standing
water could create an electrocution, shock, or fire hazard. Cut power to the charging station if it
has been exposed to standing water and contact ChargePoint before the charging station is
powered on.
10
Drainage
