1 Site Design Guidelines
1
This document describes how to design an installation site for the ChargePoint® Express 280 DC fast
charging station and install the Concrete Mounting Template, before station installation. An Express 280
station can be installed to operate by itself (called “Standalone”) or to share power with one other Express
280 station for higher throughput (called “Paired”).
IMPORTANT: You must be a licensed electrician and complete online training to become a
ChargePoint certified installer. If you do not complete training, you cannot access the
ChargePoint network to complete installation.
Find online training at: chargepoint.com/installers
If the charging station is not installed by a ChargePoint certified installer, using a ChargePoint
approved method, it is not covered under warranty and ChargePoint is not responsible for any
malfunctions.
Accessing ChargePoint Documentation
Access ChargePoint documents at chargepoint.com/guides.
Document Content Primary Audiences
Datasheet Full station specifications Site designer, installer, and
station owner
Site Design Guide Civil, mechanical, and electrical
guidelines to scope and construct
the site
Site designer or engineer of
record
Concrete Mounting Template
Guide
Instructions to embed the charging
station template in a concrete pad
with anchor bolts and conduit
placement
Site construction contractor
Surface Conduit Entry Kit
Guide
Instructions for sites where conduit
cannot be run underground
Installer
Construction Signoff Form Checklists used by contractors to
ensure the site is correctly
completed and ready for product
installation
Site construction contractor
Installation Guide Anchoring, wiring, and powering on Installer
