Cable Wiring
OFAF Master Cable
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
Figure 18: OFAF Master Cable wiring configuration. Numbering
as viewed from side of RJ-45 connector opposite latch.
Standard Cable
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
Figure 19: Standard reverse RJ-45 network cable configuration.
Numbering as viewed from side of connector opposite latch.
Note: Pressing Stop Fill will delay the automatic fill circuit for 30 minutes. To initiate
the Auto Fill Circuit restart the controller.
