TEC 3000 Operating and Maintenance Freezer Manual
13289499 Rev H • 20
5.3 TEC 3000 Display
The TEC 3000 front panel display is the primary user interface for the TEC 3000. There are two
display options: text or symbolic.
Text Display
Symbolic Display
LDC Display
20 x 4 LCD with backlight
START FILL Key
Used to manually initiate a fill
STOP FILL Key
Used to manually terminate a fill – Disables Auto Fill for 30 minutes
SETUP Key
Used to access Setup Menus and parameters
ALARM MUTE Key
Used to silence the audible alarm for 30 minutes. Will reset the latching alarm once it has
been corrected
▲ Key
Used to increase parameter values or to toggle “YES/NO” or “ON/OFF” values
▼ Key
Used to decrease parameter values or to toggle “YES/NO” or “ON/OFF” values
ESC Key
Used to escape or exit a menu or menu level
ENTER Key
Used to select a menu or value or save a setting change
