CHART MVE 1839 - MVE Stock Series

MVE Biological Systems
TEC 3000 Operating and Maintenance Freezer Manual
13289499 Rev G • 11
5.1.3. MVE Stock Series
The MVE Stock Series freezers are designed primarily for storage of either vials or
straws on canes in liquid nitrogen, but can also be used for vapor phase storage with the
vapor storage accessory package. Dual lids on the MVE 1318 and two-tier turn-trays in
the MVE 816P-2T-190 and the MVE 1877P-2T-150 are example features of these
freezers built for durability and ergonomic sample retrieval.
Freezer
Model
Minimum
Door Width
in. (mm)
Minimum
Ceiling Height
in. (mm)
Liftover
Height
in. (mm)
Weight
Empty
lbs. (kg)
Weight
Liquid Full
lbs. (kg)
Qty of
Casters
Direct Load per
Caster (Full)
lbs. (kg)
MVE 808
31 (787)
65.1 (1653)
39.1 (992)
250 (114)
660 (300)
3
220 (100)
MVE 816P-
2T-190
32 (813)
59.5 (1512)
48.3 (1227)
475 (215)
1155 (524)
4
288.75 (131)
MVE 1318
42 (1067)
62.8 (1595)
43.6 (1107)
469 (213)
1328 (602)
3
332 (201)
MVE
1842P-150
60 (1524)
73 (1853)
42.5 (1078)
1167 (530)
2798 (1270)
4
699.5 (317.5)
MVE
1877P-2T-
150
60 (1524)
67.5 (1716)
36.3 (923)
1600 (726)
4094 (1857)
4
1023.5 (464.25)
Figure 2: Diagram showing innovative two-tier turn-tray designed to
maximize storage capacity while minimizing floor space.
