PRODUCT INFORMATION CLINICIAN
OK Key
The “OK” key is used as a means of putting the stamp of
“locking” in parameter selections and item selections.
Backside Labeling
The labeling, found on the back of the device, details the
standards to which this device has been tested (i.e., ETL
approval). Federal law (USA) restricts this device to sale by
or on the order of a physician.
PRE-PROGRAMMED AND THREE CUSTOM
REGIMENS
Regimens are the centerpiece of the Chattanooga
Continuum. They are designed for very specific clinical
applications and are intended to simplify the use of the
device by allowing the clinician to educate the patient
on the use of the device with very little eort. The
Chattanooga Continuum device categorizes NMES Pre-set
and Custom programs by Large Muscle and Small Muscle.
An example of Large muscles would be the quadriceps,
hamstrings, gluteus maximus and medius, adductor
magnus, latissimus dorsi and abdominal musculature.
Small muscle examples would be anterior tib, bicep,
deltoid, supraspinatus, teres minor, subscapularis, and the
intrinsic foot and hand muscles.
NMES REGIMENS
Large Muscle Atrophy — Summary
This is a sequenced, -channel program for strengthening
and re-educating large atrophied muscles. All parameters
are preset with the exception of Treatment Time, O Time
and the Pulse Rate which can be adjusted by the clinician.
The range of adjustments for Treatment Time, O Time
and Pulse Rate are listed in the table below.
Adjustable Parameters Range Default Setting
Treatment Time 5-60 min or Continuous 30 min
O Time 0-60 sec 30 sec
Pulse Rate 2 Hz-150 Hz 50 Hz
Preset Parameters Settings
Waveform Type SYM
Cycling Type LAG
Pulse Width/Duration 300 μs
Lag Delay 3 sec
CH 1 Ramp+ 3 sec
CH 1 On Time 12 sec
CH 1 Ramp– 2 sec
CH 2 Ramp+ 2 sec
CH 2 On Time 9 sec
CH 2 Ramp– 1 sec
