PRODUCT INFORMATION CLINICIAN
Small Muscle Custom / Remote — Summary
This option oers similar stimulation as Small Muscle
Spasm and Trigger- Point if no external Hand Switch is
detected.
Adjustable Parameters Range Default Setting
Treatment Time 5-60 min or Continuous 30 min
O Time 0-60 sec 30 sec
Pulse Rate 2 Hz-150 Hz 35 Hz
Pulse Width 48 μs-400 μs 300 μs
Waveform Type SYM, ASY SYM
Cycling Type SIM, 1 CH, ALT, LAG SIM
Lag Delay 0-5 sec 0 sec
CH 1 Ramp+ 0-5 sec 2 sec
CH 1 On Time 0-60 sec 10 sec
CH 1 Ramp– 0-5 sec 2 sec
CH 2 Ramp+ 0-5 sec 2 sec
CH 2 On Time 0-60 sec 10 sec
CH 2 Ramp– 0-5 sec 2 2 sec
If used with an external Switch, continuous stimulation
is available for gait training protocol. The intensity of
each channel is independently adjustable. Waveform,
pulse width, and pulse rate parameters have default
settings and are the adjustable parameters (within range).
Depending on the cycle selected, all parameters may not
be adjustable.
TENS REGIMENS
TENS Knee — Summary
This treatment option is a -channel Modulated Amplitude
program for the management of acute or chronic pain
control in the knee. All parameters are preset with the
exception of Treatment Time and the Pulse Rate, which
can be adjusted by the clinician.
Adjustable Parameters Range Default Setting
Treatment Time 5-60 min or Continuous 30 min
Pulse Rate 2 Hz-150 Hz 100 Hz
Preset Parameters Settings
Cycling Time 12 sec
Attenuated Span 40%
Pulse Width 300 μs
Mode MOD
TENS Shoulder — Summary
This treatment option is a -channel Simple Modulated
Pulse (SMP) program for the management of acute or
chronic pain control in the shoulder. This treatment option
modulates the pulse rate and the pulse width at the same
time. All parameters are preset with the exception of
Treatment time and the Pulse Rate , which can be adjusted
by the clinician.
Adjustable Parameters Range Default Setting
Treatment Time 5-60 min or Continuous 30 min
Pulse Rate 2 Hz-150 Hz 100 Hz
Preset Parameters Settings
Cycling Time 12 sec
Pulse Width 300 μs
Mode SMP
