PRODUCT INFORMATION CLINICIAN
NMES REGIMENS
NMES large muscle:
• Amplitude at ohm is Vpeak (DC
component .%)
• Amplitude at ohm is Vpeak (DC
component .%)
NMES small muscle:
• Amplitude at ohm is Vpeak (DC
component .%)
• Amplitude at ohm is Vpeak (DC
component .%)
TENS REGIMENS
TENS SMP
• Amplitude at ohm is Vpeak (DC
component %)
• Amplitude at ohm is Vpeak (DC
component .%)
TENS MOD:
• Amplitude at ohm is Vpeak (DC
component .%)
• Amplitude at ohm is Vpeak (DC
component .%)
PROGRAMMING THE DEVICE
Setting Treatment Parameters
Programming the Chattanooga Continuum is designed
to be intuitive. The Chattanooga Continuum has
been engineered to guide the clinician through the
programming process. The clinician will first set up the
parameters for treatment and then proceed to restrict the
user’s ability to reprogram the unit. In essence, the clinician
will set up the device such that the user has only to press
one button before starting the treatment.
NMES Parameters
. Power ON the device by depressing the
ON/OFF ( ) button.
. Press the top soft key on the left to select
“NMES” programming.
. Select the Muscle Type – either Large or Small Muscle.
. Select Treatment type – Atrophy, Spasm, Point,
or Custom.
. Using left side soft key, scroll to the desired
parameter item.
. Using right side soft keys, scroll parameter value
up or down.
. Press the Home button to get back to the Option menu.
. Press the soft key labeled “CONFIG.”
. Press right side soft key labeled “LOCKS.”
. Using left soft keys, scroll to desired item “NMES
L.MUSCLES” or “NMES S.MUSCLES.”
. Press the upper right soft key until a locked icon displays.
. Press Home button to accept the change.
. Press the “NMES” button, a lock must be visible beside
the previously selected item (“LARGE MUSCLE” or
“SMALL MUSCLE”).
. Select the locked treatment to go to the
“In-Progress” screen.
. Set up patient with electrodes and ramp-up intensity.
