TENS Parameters
. Power ON the device by pressing the
ON/OFF ( ) button.
. Press bottom soft key on the left to select
TENS programming.
. Select the body part by scrolling thru options and
press “OK.”
. Using left side soft key, scroll to the desired
parameter item.
. Using right side soft keys, scroll parameter value
up or down.
. Press the Home button to get back to the Option menu.
. Press soft key labeled “CONFIG.”
. Press right side soft key labeled “LOCKS.”
. Using lower left soft key, scroll to item “TENS.”
. Press the upper right soft key until a locked icon
displays.
. Press Home button to accept the change.
. Press the “TENS” button ( a lock must be visible beside
it) to go to the “In-Progress” screen.
. Set up patient with electrodes and ramp up the
intensity.
Locking the Device
The Chattanooga Continuum has been designed with
a feature that allows the clinician to set up a treatment
regimen for each of the three dierent stimulation therapy
type programs.
This feature allows the clinician to be confident that the
treatment instructions are more likely to be followed by
the patient during the course of treatment.
After having set up a treatment’s parameters, the clinician
can do as follows:
. On the main options screen, press “CONFIG” to get to
the CONFIG menu.
. Press “LOCKS” (Lower Right Soft Key).
. Using the Left Soft Keys, scroll through available items
(NMES L.MUSCLES, NMES S.MUSCLES and TENS).
Initially, these items will show an unlock icon to the right
on the LCD screen.
. For each item, press the upper right hand soft key once.
This will show the lock icon, an image of a closed pad lock.
. Press the Home key.
. Notice the small lock beside the treatment option
that was previously locked. Notice also that when the
corresponding soft key is pressed, user transitions directly
to the In-Progress screen.
This can be done for all treatment types.
