PRODUCT INFORMATION CLINICIAN
Large Muscle Custom / Switch — Summary
This option oers similar stimulation as Large Muscle
Spasm and Trigger- Point if no external Foot Switch is
detected.
Adjustable Parameters Range Default Setting
Treatment Time 5-60 min or Continuous 30 min
O Time 0-60 sec 30 sec
Pulse Rate 2 Hz-150 Hz 35 Hz
Pulse Width 48 μs-400 μs 300 μs
Waveform Type SYM, ASY SYM
Cycling Type SIM, 1 CH, ALT, LAG SIM
Lag Delay 0-5 sec 0 sec
CH 1 Ramp+ 0-5 sec 2 sec
CH 1 On Time 0-60 sec 10 sec
CH 1 Ramp– 0-5 sec 2 sec
CH 2 Ramp+ 0-5 sec 2 sec
CH 2 On Time 0-60 sec 10 sec
CH 2 Ramp– 0-5 sec 2 2 sec
If used with an external Switch, continuous stimulation
is available for gait training protocol. The intensity of
each channel is independently adjustable. Waveform,
pulse width, and pulse rate parameters have default
settings and are the adjustable parameters (within range).
Depending on the cycle selected, all parameters may not
be adjustable.
Small Muscle Atrophy — Summary
This is a -channel program for strengthening and re-
educating small atrophied muscles. All parameters are
preset with the exception of Treatment Time, O Time
and the Pulse Rate which can be adjusted by the clinician.
The range of adjustments for Treatment Time, O Time
and Pulse Rate are listed in the table below.
Adjustable Parameters Range Default Setting
Treatment Time 5-60 min or Continuous 30 min
O Time 0-60 sec 30 sec
Pulse Rate 2 Hz-150 Hz 35 Hz
Preset Parameters Settings
Waveform Type ASY
Cycling Type SIM
Pulse Width 300 μs
Lag Delay 0 sec
CH 1 Up Time 2 sec
CH 1 On Time 10 sec
CH 1 Down Time 2 sec
CH 2 Up Time 2 sec
CH 2 On Time 10 sec
CH 2 Down Time 2 sec
