DMX Channel Modes, Assignments, and Values
31-Channel
Channel Function Value Setting
1
Red
000 ó 255
0–100%
Section 1
2
Green
000 ó 255
0–100%
3
Blue
000 ó 255
0–100%
4
Red
000
ó
255
0–100%
Section 2
5
Green
000 ó 255
0–100%
6
Blue
000 ó 255
0–100%
7
Red
000 ó 255
0–100%
Section 3
8
Green
000 ó 255
0–100%
9
Blue
000 ó 255
0–100%
10
Red
000 ó 255
0–100%
Section 4
11
Green
000 ó 255
0–100%
12
Blue
000 ó 255
0–100%
13
Red
000
ó
255
0–100%
Section 5
14
Green
000 ó 255
0–100%
15
Blue
000 ó 255
0–100%
16
Red
000 ó 255
0–100%
Section 6
17
Green
000 ó 255
0–100%
18
Blue
000 ó 255
0–100%
19
Red
000 ó 255
0–100%
Section 7
20
Green
000 ó 255
0–100%
21
Blue
000 ó 255
0–100%
22
Red
000 ó 255
0–100%
Section 8
23
Green
000 ó 255
0–100%
24
Blue
000 ó 255
0–100%
25
Red
000 ó 255
0–100%
Section 9
26
Green
000 ó 255
0–100%
27
Blue
000 ó 255
0–100%
28 Auto Programs
000 ó 010
No function
011 ó 040
Chase 1
041 ó 080
Chase 2
081 ó 120
Chase 3
121 ó 160
Chase 4
161 ó 200
Chase 5
201
ó
240
Chase 6 (run Chases 1–4)
241 ó 255
Sound-Active mode
29
Speed
000 ó 255
Auto programs speed (slow to fast)
30
Dimmer
000 ó 255
0–100%
31 Shutter
000 ó 010
No function
011 ó 255
Strobe (slow to fast)
