Chauvet CORE - DMX Channel Modes, Assignments, and Values (Cont.); 27-Channel

Page 14 of 23 CORE™ 3x3 User Manual Rev. 1
DMX Channel Modes, Assignments, and Values (cont.)
27-Channel
Channel Function Value Setting
1
Red
000 ó 255
0–100%
Section 1
2
Green
000 ó 255
0–100%
3
Blue
000 ó 255
0–100%
4
Red
000
ó
255
0–100%
Section 2
5
Green
000 ó 255
0–100%
6
Blue
000 ó 255
0–100%
7
Red
000 ó 255
0–100%
Section 3
8
Green
000 ó 255
0–100%
9
Blue
000 ó 255
0–100%
10
Red
000 ó 255
0–100%
Section 4
11
Green
000 ó 255
0–100%
12
Blue
000 ó 255
0–100%
13
Red
000
ó
255
0–100%
Section 5
14
Green
000 ó 255
0–100%
15
Blue
000 ó 255
0–100%
16
Red
000 ó 255
0–100%
Section 6
17
Green
000 ó 255
0–100%
18
Blue
000 ó 255
0–100%
19
Red
000 ó 255
0–100%
Section 7
20
Green
000 ó 255
0–100%
21
Blue
000 ó 255
0–100%
22
Red
000 ó 255
0–100%
Section 8
23
Green
000 ó 255
0–100%
24
Blue
000 ó 255
0–100%
25
Red
000 ó 255
0–100%
Section 9
26
Green
000 ó 255
0–100%
27
Blue
000 ó 255
0–100%
