DMX Channel Modes, Assignments, and Values (cont.)
9-Channel
Channel Function Value Setting
1
Dimmer
000 ó 255
0–100%
2
Red
000 ó 255
0–100%
3
Green
000 ó 255
0–100%
4
Blue
000 ó 255
0–100%
5 Shutter
000 ó 010
No function
011 ó 255
Strobe (slow to fast)
6
Custom Color and
Color Temperature
000 ó 010
No function
011 ó 030
Red 100% + Green 0–100%
031 ó 050
Red 100%–0 + Green 100%
051 ó 070
Green 100% + Blue 0–100%
071 ó 090
Green 100%–0 + Blue 100%
091 ó 110
Red 0–100% + Blue 100%
111 ó 130
Red 100% + Blue 100%–0
131 ó 150
Red 100% + Green 0–100% + Blue 0–100%
151 ó 170
Red 100%–0 + Green 100%–0 + Blue 100%
171 ó 200
Red 100% + Green 100% + Blue 100%
201 ó 205
Color temperature 1
206 ó 210
Color temperature 2
211 ó 215
Color temperature 3
216 ó 220
Color temperature 4
221 ó 225
Color temperature 5
226 ó 230
Color temperature 6
231 ó 235
Color temperature 7
236
ó
240
Color temperature 8
241 ó 245
Color temperature 9
246 ó 250
Color temperature 10
251 ó 255
Color temperature 11
7 Auto Programs
000 ó 010
No function
011 ó 040
Chase 1
041 ó 080
Chase 2
081 ó 120
Chase 3
121 ó 160
Chase 4
161 ó 200
Chase 5
201 ó 240
Chase 6 (run Chases 1–4)
241 ó 255
Sound-Active mode
8
Speed
000 ó 255
Auto programs speed (slow to fast)
9 Dimmer Mode
000 ó 051
Dimmer mode manually set in Menu Options
052 ó 101
Dimmer mode off
102 ó 152
Dimmer mode 1 (fast speed)
153 ó 203
Dimmer mode 2 (middle speed)
204 ó 255
Dimmer mode 3 (slow speed)
