Chauvet DMX-55 DMX User Manual

Operating Instructions
DMX-55 User Manual 10 2006-01-11 11:59:07
DELETING A SCANNER’S DMX CHANNEL SETTINGS
Action 
1) Press the Program button until the LED
blinks.
2) Hold the MODE button and press FINE.
The Reverse LED will light.
3) Tap the Scanner button delete settings.
4) Press the MODE and AUTO/Del
buttons at the same time. All LEDs will
flash three times to confirm operation.
Notes 
Assign mode will also work in this case.
CLEAR ALL SCANNER’ S DMX CHANNELS
Action 
1) Turn the power off.
2) Press and hold the MODE and
AUTO/Del buttons at the same time.
3) Turn the power back on. All LEDs will
flash briefly to confirm operation.
Notes 
Assign mode will also work in this case.
DISPLAY PAN/TILT DMX CHANNELS
Action 
1) Press the FINE and MODE buttons at
the same time putting the controller into
Assign mode.
Press the FINE and MODE buttons once
more to change to Reverse mode.
2) Press the Scanner button that you wish
to display Pan and Tilt DMX values for.
Notes 
FADE TIME SETTINGS
Action 
1) With power on the unit off, press the
MODE and TAP/Display buttons at the
same time.
2) Apply power to the unit while holding
the buttons pressed above.
3) Once unit is on, tap the TAP/Display
button to change between Fade Time
and Assign Fade Time.
Press the MODE and TAP/Display
buttons at the same time to store your
setting into memory.
4) You can also exit without saving by
pressing the Blackout button.
Notes 
or
ALL CH
FD
TIME
ONLY X/Y
FD
TIME

Chauvet DMX-55 DMX Specifications

Power

operating range	DC 9V-12V 500mA min
adapter	Provided

Operating Environment

maximum ambient temperature	45°C (113° F)

Weight and Dimensions

length	514 mm (20.25 in)
width	89 mm (3.5 in)
height	171 mm (6.75 in)
weight	2.7 Kg (6 lbs)
