Chauvet DMX-55 DMX User Manual

Operating Instructions
DMX-55 User Manual 14 2006-01-11 11:59:07
ADD A STEP
Action 
1) Press the Program button until the LED
blinks.
2) Press the corresponding button to the
chase you wish to add a step to.
3) Press the TAP/Display button so that
the LCD display shows the current step.
4) Use the  BANK and  BANK buttons
to scroll to the step you wish to add a
step after.
5) Press the MIDI/REC button. The LCD
will display one step number higher than
previous.
6) Tap the TAP/Display button again. The
LCD will now display the current chase,
scene and bank. Create a desired
scene and record it as a new step or
select a previously programmed scene
to add to the chase.
7) Press the MIDI/REC button again. All
LEDs will flash three times to confirm
the save.
Notes 
DELETE A STEP
Action 
1) Press the Program button until the LED
blinks.
2) Select the chase that contains the step
you want to delete.
3) Press the TAP/Display button to
display the current step number.
4) Use the  BANK and  BANK buttons
to scroll to the step you wish to delete.
5) Tap the AUTO/Del button to delete the
step. All LEDs will flash three times to
confirm the deletion process.
Notes 
DELETE A CHASE
Action 
1) Press and hold the Chase button you
want to delete.
2) Then, press and hold the AUTO/Del
button until all LEDs flash three times.
Notes 

Chauvet DMX-55 DMX Specifications

Power

operating range	DC 9V-12V 500mA min
adapter	Provided

Operating Environment

maximum ambient temperature	45°C (113° F)

Weight and Dimensions

length	514 mm (20.25 in)
width	89 mm (3.5 in)
height	171 mm (6.75 in)
weight	2.7 Kg (6 lbs)
