Chauvet DMX-55 DMX User Manual

Operating Instructions
DMX-55 User Manual 11 2006-01-11 11:59:07
SCENE PROGRAMMING
ENTERING PROGRAMMING MODE
1) Press the Program button until the LED blinks.
CREATE A SCENE
A scene is a static lighting state. The DMX-55 can save 240 scenes.
Action 
1) Press the Program button until the LED
blinks.
2) Position SPEED and FADE TIME
sliders all the way down.
3) Select the SCANNERS you wish to
include in your scene.
4) Compose a look by moving the sliders
and joystick.
5) Choose BANK.
6) Tap MIDI/Rec button.
7) Select a SCENES button to store.
8) Repeat steps 3 through 7 as necessary.
9) To exit program mode, hold the MODE
button and press FINE.
Notes 
Deselect Blackout if LED is lit.
You can select more than one fixture.
You can access channels 9~16 by pressing the Page
Select button. This is necessary for fixtures that use
more than 8 channels of control.
There are 8 scenes available in every bank.
-> All LEDs will flash three times to confirm. The
LED display will no indicate the Scene number and
Bank number used.
Shortcut: {Programming Fixtures}  Press [Save]  Select [Button 1~24] to store to memory
SCENE EDIT
Action 
1) Press the Program button until the LED
blinks.
2) Use  BANK and  BANK buttons to
change banks.
3) Tap the scene to edit within the bank.
4) Follow steps 2 through 4 from “Create a
Scene”
5) Tap MIDI/Rec button.
6) Tap the same scene number originally
selected on step 3.
Notes 
Deselect Blackout if LED is lit.
Remember this scene number!
Scene edit works by overriding a scene.

Chauvet DMX-55 DMX Specifications

Power

operating range	DC 9V-12V 500mA min
adapter	Provided

Operating Environment

maximum ambient temperature	45°C (113° F)

Weight and Dimensions

length	514 mm (20.25 in)
width	89 mm (3.5 in)
height	171 mm (6.75 in)
weight	2.7 Kg (6 lbs)
