3 Front Panel Operation
The front panel contains one LCD screen, two indicator LEDs, and two buttons. The operating
controls are all located on the frontpanel.
3.1 Main Operation Menus
The top-level menu of the front panel includes 6 parts: Info, SV, Mode, Power, Data and Set.
Info is the basic information of firmware such as SN, PN and etc. SV is the display of satellite
situation. Mode is the important part which illustrate the work mode and users can select the
mode according to their needs. Power shows the electric quantity of two batteries. Data is
used to set static mode and Set is to set the device according to personal habits including
language, brightness, etc.
The details of main operation are as follows and they are concluded two tables. The first table
includes 5 parts: Info, SV, Power, Data and Set and the second table displays details of Data.
Top-level Menu
Second-level Menu
Description
SN 3411956
Describe the main information of this
PN A19318-430901-060002
machine. SN displays the Serial Number
-015701
of the receiver. PN displays the Part
-020104
Number of the receiver. Version displays
Version 2.0.7
the firmware version. Register displays
Info
Register 2030/12/31
Static off
the expiry date of registration code.
Static displays if the static is on or not.
Sample 5S
Format displays the data type.
Format HCN
Network displays the if a sim card
Diff Age 0.0S
inserts the RTK. IMEI is International
Network No Sim Card
Mobile Equipment Identity which is
IMEI 861529049455435
used to identify the RTK.
Total: 30/30
Indicate the total number of satellites
that have been tracked and the number
of satellites tracked of each
constellation, where BDS represents
BeiDou, GLO represents GLONASS, and
GAL represents Galileo.
GPS: 10/10
SV
BDS: 10/10
GLO: 4/6
GAL: 4/4
