Check-line DTS-200 - Page 4

– 3 –
Numeric display
Display with Bargraph
Adjusted material
diameter
Info on material
Damping
Current reading
Memory mode (data
stored in the memory)
Battery status indicator
Measurement unit
MIN/MAX Alarm
Adjusted material
diameter
Info on material
Damping
Current reading
MIN.-alarm value
Tension range
Memory mode (data
stored in the memory)
Battery status indicator
Measurement unit
Peak values MIN/MAX AlarmMAX.-alarm value
FIG. 2
FIG. 3
