6000 and 7000 Appliances Installing and Removing Memory
6000 and 7000 Appliances Replacing Memory|11
6500 Appliances DIMM Configuration
The 6500 appliances have a default memory configuration of 8 GB with one DIMM in memory slot
number 2. You can upgrade to 16 GB or 32 GB. Use the applicable upgrade procedure below.
8 GB Default Configuration
Top View
(front panel of the appliance is at the bottom of the diagram)
To upgrade to Use DIMMs Procedure Slots
16 GB 2 x 8 GB Install two 8 GB DIMMs In memory slots 2 and 4
