6000 and 7000 Appliances Installing and Removing Memory
6000 and 7000 Appliances Replacing Memory|8
6200/6400/6600/6700 Base Appliances DIMM
Configuration
The 6200/6400/6600/6700 Base appliances have a default memory configuration of 8 GB with one
DIMM in memory slot A1. You can upgrade to 16 GB or 32 GB.
Use the applicable upgrade procedure below.
8 GB Default Configuration
Top View
(front panel of the appliance is at the bottom of the diagram)
To upgrade to Use DIMMs Procedure Slots
16 GB 2 x 8 GB Install two 8 GB DIMMs In memory slots A1 and B1
16 GB Upgraded Configuration
Top View
(front panel of the appliance is at the bottom of the diagram)
