6000 and 7000 Appliances Installing and Removing Memory
6000 and 7000 Appliances Replacing Memory|20
7000 Plus Appliances DIMM Configuration
The 7000 Plus appliances have a default memory configuration of 32 GB with two 16 GB DIMMs in
memory slots 3 and 4. You can upgrade to 64 GB. Use the upgrade procedure below.
32 GB Default Configuration
Top View
(front panel of the appliance is at the bottom of the diagram)
To upgrade to Use DIMMs Procedure Slots
64 GB 4 x 16 GB Install four 16 GB DIMMs In memory slots 2, 3, 4, and 5
64 GB Upgraded Configuration
Top View
(front panel of the appliance is at the bottom of the diagram)
