19000 / 29000 Appliances Hardware
Quantum Force 19000 and 29000 Appliances Getting Started Guide|46
Item Component Description
10 System LEDs See
"System LEDs" on page48
.
11 USB Type-C port For a serial connection to the appliance.
12 Unavailable
expansion slot
Expansion slot not in use.
13 Expansion line
cards
In the Gaia OS on the appliance, these interface names are
assigned:
In 19200:
n
The bottom row of slots (from left to right):
eth1-0X, eth2-0X, eth3-0X, and eth4-0X.
In 29100 / 29200:
n
The top row of slots (from left to right):
eth5-0X, eth6-0X, and eth7-0X.
n
The bottom row of slots (from left to right):
eth1-0X, eth2-0X, eth3-0X, and eth4-0X.
For port speed and port activity LED descriptions, see the
relevant chapter in
Installing and Removing Line Cards
.
