19000 / 29000 Appliances Hardware
Quantum Force 19000 and 29000 Appliances Getting Started Guide|49
Item Icon Component Description
5 Location
beacon
n
Off - Location beacon is turned off
n
Blinking blue - Location beacon is turned on in
Gaia Portal or Gaia Clish
n
Solid blue - Location beacon is turned on with
the Locator button
Note - Turn off the Location beacon LED the same
way you turned it on.
Rear Panel
19200 / 29100 / 29200
Item Component Description
1 Grounding
lugs
Used to connect grounding.
2 Cover screws Loosen screws to remove the cover of the appliance.
3 ESD
grounding
point
When servicing the appliance, connect an ESD strap to this
point.
