CHIEF MI200T - Technical Specifications; Icons

32
12 – Technical specifications
ELECTRICAL CHARACTERISTICS
Nominal input voltage : U1N
3~200V
3~208V
3~230V
3~240V
Frequency
50/60 Hz
Permanent input current : I1N
40 A
Power at 50 % duty cycle : S50
20 kVA
Permanent input power : Sp
14 kVA
Maximum welding input power : Smax
80 kVA
Secondary voltage : U2d
6.95V
7.2V
8V
8.3V
Maximum short-circuit output current : I2cc
12 500A
13 000A
14 500A
14 500A
Maximum permanent output current : I2P
1 800 A
Circuit breaker
40 A Kurve D
Earth Leakage Circuit Breaker
30 mA
Duty cycle
2%
THERMAL CHARACTERISTICS
Ambient temperature range
+5°C +45°C
Transport and storage temperature range
-20°C +70°C
Hygrometry
80 %
Altitude
2000m
Thermal protection by thermistor on the diodes bridge
70 °C
MECHANICAL CHARACTERISTICS
Protection rating
IP21
Width
610 mm
Depth
720 mm
Height
2260 mm
Weight
100 kg
Weight of clamp
10 kg
Network cable length
8.000 mm
Clamp cable length reference : CEL019614
4.000 mm
Clamp cable length reference : CEL020320
6.000 mm
PNEUMATIC CHARACTERISTICS
Maximum air pressure P1
10 bar
Liquid flow rate
2L/min
Minimum regulated force : F min
100 daN
Maximum regulated force with C clamp : F max
550 daN
13 - Icons
V
Volt
A
Amps
3 ~
Three-phase power supply
U 1n
Nominal input voltage
S p
Permanent input power
S max
Maximum welding input power
U 20
Alternating current defined unload
I 2 cc
Secondary current on short-circuit
IP 21
Protected against rain and moisture. No access to dangerous parts.
Caution! Read the user manual before use
Separate collection required – Do not throw in a domestic waste bin
Do not use in the open air.
Do not use the product in damp/wet environments. IP21.
Risk of interference and disturbance of electronic medical devices (i.e. pace-makers) when
near of the product.
Caution! Strong magnetic field.
People wearing active or passive implants must be informed.
Always wear suitable protective clothing to shield eyes, hands, and skin, when welding.
