R410A50Hz Universal Outdoor Series Technical Manual Floor & Ceiling Indoor Unit
104
GD Chigo Heating & Ventilation Equipment Co., Ltd.
Heating
6.6 CUA-18HR1
MODEL
CUA-18HR1
HEATING
OUTDOOR CONDITIONS
Indoor
Conditions
24ºC D
18ºC W
12ºC D
11ºC W
7ºC D
6ºC W
4ºC D
3ºC W
0ºC D
-1ºC W
-5ºC D
-6ºC W
-7ºC D
-8ºC W
15ºC
Capacity kW
10.28
8.21
6.88
6.2
5.85
5.16
4.81
Input kW.
3.16
2.52
2.12
1.99
1.9
1.79
1.68
18ºC
Capacity kW
9.67
7.72
6.45
5.81
5.49
4.85
4.52
Input kW.
2.94
2.33
1.97
1.88
1.78
1.68
1.58
20ºC
Capacity kW
8.87
7.12
5.8
5.38
5.08
4.49
4.18
Input kW.
2.71
2.15
1.71
1.75
1.66
1.55
1.46
22ºC
Capacity kW
8.21
6.56
5.51
4.96
4.66
4.13
3.85
Input kW.
2.48
2.01
1.69
1.61
1.51
1.43
1.35
27ºC
Capacity kW
7.15
5.72
4.78
4.3
4.06
3.58
3.37
Input kW.
2.15
1.75
1.46
1.38
1.32
1.24
1.15
6.7 CUA-24HR1
MODEL
CUA-24HR1
HEATING
OUTDOOR CONDITIONS
Indoor
Conditions
24ºC D
18ºC W
12ºC D
11ºC W
7ºC D
6ºC W
4ºC D
3ºC W
0ºC D
-1ºC W
-5ºC D
-6ºC W
-7ºC D
-8ºC W
15ºC
Capacity kW
13.68
10.91
9.12
8.24
7.78
6.86
6.42
Input kW.
4.78
3.76
3.12
2.95
2.78
2.68
2.54
18ºC
Capacity kW
12.85
10.27
8.56
7.68
7.31
6.42
6.01
Input kW.
4.48
3.43
2.84
2.76
2.61
2.46
2.36
20ºC
Capacity kW
11.89
9.48
7.8
7.16
6.78
5.92
5.58
Input kW.
4.08
3.26
2.33
2.31
2.26
2.22
2.15
22ºC
Capacity kW
10.95
8.76
7.31
6.58
6.24
5.5
5.12
Input kW.
3.78
2.96
2.25
2.28
2.21
2.08
1.98
27ºC
Capacity kW
9.51
7.57
6.34
5.72
5.42
4.68
4.46
Input kW.
3.27
2.45
2.14
2.08
1.98
1.83
1.68
6.8 CUA-36HR1
MODEL
CUA-36HR1
HEATING
OUTDOOR CONDITIONS
Indoor
Conditions
24ºC D
18ºC W
12ºC D
11ºC W
7ºC D
6ºC W
4ºC D
3ºC W
0ºC D
-1ºC W
-5ºC D
-6ºC W
-7ºC D
-8ºC W
15ºC
Capacity kW
19.64
15.74
13.12
11.82
11.15
9.81
9.19
Input kW.
6.01
4.81
4.01
3.8
3.59
3.39
3.22
18ºC
Capacity kW
18.49
14.78
12.32
11.12
10.49
9.21
8.63
Input kW.
5.65
4.51
3.75
3.6
3.38
3.19
2.98
20ºC
Capacity kW
17.12
13.7
11.55
10.25
9.7
8.54
8.02
Input kW.
5.23
4.18
3.38
3.23
3.13
2.96
2.78
22ºC
Capacity kW
15.75
12.62
10.51
9.45
8.94
7.88
7.35
Input kW.
4.81
3.82
3.18
3.02
2.9
2.71
2.54
27ºC
Capacity kW
13.66
11.03
9.13
8.22
7.74
6.86
6.39
Input kW.
4.14
3.32
2.78
2.64
2.48
2.35
2.21
