R410A50Hz Universal Outdoor Series Technical Manual Floor & Ceiling Indoor Unit
111
GD Chigo Heating & Ventilation Equipment Co., Ltd.
No.
Part Name
Quantity
No.
Part Name
Quantity
1
Connection board for air guide B
1
26
fan mounting plate
1
2
connecting shaft
2
27
Indoor fan motor
1
3
air guide frame
1
28
scroll case
3
4
Connection board for air guide
1
29
guide rail
2
5
maskIMD
1
30
Right separating board
1
6
display panel
1
31
Terminal
1
7
display lamp panel
1
32
Hexagon bolts M8×30
4
8
wire of display lamp panle
1
33
Right cover
1
9
Guard vane
24
34
Right sealplate
3
10
connecting rod
2
35
Front panel
3
11
Guard vane 2
2
36
Insulation pipes
3
12
top Cover
1
37
filter bar
6
13
Rear cover
1
38
filter screen
1
14
Right mounting plate of evaporator
1
39
Air inlet grille
1
15
Right mounting plate of evaporator
1
40
filter bar 2
1
16
Right mounting holder
1
41
upper E-part box cover
1
17
Left sealplate
1
42
Indoor PCB
1
18
Left cover
1
43
lower E-part box cover
1
19
left mounting holder
1
44
Communication line
1
20
Lelf separating board
1
45
pipe temperature probe
2
21
Indoor fan motorleft
1
46
indoor temperature probe
8
22
left mounting plate of evaporator
1
47
connecting wire of display lamp
panle
1
23
outlet holder
1
48
Rear cover holder
2
24
evaporator
1
49
E-part box holder
1
25
water pan
1
