6.10 CCA-36HR1
MODEL
CCA-36HR1
HEATING
OUTDOOR CONDITIONS
Indoor Conditions
24ºC D
18ºC W
7ºC D
6ºC W
2ºC DB
1ºC WB
-5ºC D
-6ºC W
-7ºC D
-8ºC W
15ºC
Capacity kW
15.15
12.22
10.01
9.08
8.36
Input kW.
3.62
3.21
3.03
2.94
2.71
20ºC
Capacity kW
14.68
11.55
9.36
8.79
8.09
Input kW.
3.95
3.24
3.15
3.04
2.96
27ºC
Capacity kW
13.72
10.89
8.79
8.56
7.61
Input kW.
4.45
3.62
3.53
3.41
3.15
6.11 CCA-48HR1
MODEL
CCA-48HR1
HEATING
OUTDOOR CONDITIONS
Indoor Conditions
24ºC D
18ºC W
7ºC D
6ºC W
2ºC DB
1ºC WB
-5ºC D
-6ºC W
-7ºC D
-8ºC W
15ºC
Capacity kW
19.82
16.02
13.15
11.92
11.15
Input kW.
5.85
5.08
4.35
4.11
3.87
20ºC
Capacity kW
19.22
15.4
12.38
11.56
10.69
Input kW.
6.38
5.26
4.82
4.38
4.15
27ºC
Capacity kW
18.03
14.35
11.62
11.32
10.12
Input kW.
6.79
5.88
5.22
4.78
4.47
6.12 CCA-60HR1
MODEL
CCA-60HR1
HEATING
OUTDOOR CONDITIONS
Indoor Conditions
24ºC D
18ºC W
7ºC D
6ºC W
2ºC DB
1ºC WB
-5ºC D
-6ºC W
-7ºC D
-8ºC W
15ºC
Capacity kW
22.66
18.32
14.98
13.59
12.72
Input kW.
6.68
5.81
5.02
4.72
4.44
20ºC
Capacity kW
21.96
17.6
14.12
13.23
12.21
Input kW.
7.33
5.93
5.53
5.12
4.76
27ºC
Capacity kW
20.56
16.41
13.24
12.87
11.52
Input kW.
7.76
6.73
5.97
5.51
5.15
