6.7 CCA-18HR1
MODEL
CCA-18HR1
HEATING
OUTDOOR CONDITIONS
Indoor Conditions
24ºC D
18ºC W
7ºC D
6ºC W
2ºC DB
1ºC WB
-5ºC D
-6ºC W
-7ºC D
-8ºC W
15ºC
Capacity kW
9.85
6.55
5.73
4.92
4.59
Input kW.
3.1
2.07
1.9
1.75
1.65
18ºC
Capacity kW
9.23
6.15
5.39
4.62
4.31
Input kW.
2.91
1.95
1.8
1.65
1.56
20ºC
Capacity kW
8.54
5.8
4.99
4.23
3.99
Input kW.
2.65
1.7
1.65
1.53
1.44
22ºC
Capacity kW
7.85
5.25
4.59
3.93
3.68
Input kW.
2.48
1.65
1.53
1.41
1.32
27ºC
Capacity kW
6.84
4.56
3.99
3.42
3.2
Input kW.
2.16
1.44
1.32
1.23
1.15
6.8 CCB-18HR1
MODEL
CCB-18HR1
HEATING
OUTDOOR CONDITIONS
Indoor Conditions
24ºC D
18ºC W
7ºC D
6ºC W
2ºC DB
1ºC WB
-5ºC D
-6ºC W
-7ºC D
-8ºC W
15ºC
Capacity kW
10.31
6.85
6.01
5.15
4.81
Input kW.
3.24
2.13
2.01
1.83
1.73
18ºC
Capacity kW
9.68
6.44
5.62
4.84
4.52
Input kW.
3.02
2.02
1.87
1.72
1.62
20ºC
Capacity kW
8.95
5.8
5.22
4.46
4.18
Input kW.
2.81
1.73
1.73
1.59
1.51
22ºC
Capacity kW
8.22
5.27
4.81
4.12
3.82
Input kW.
2.58
1.72
1.6
1.47
1.38
27ºC
Capacity kW
7.15
4.78
4.16
3.56
3.35
Input kW.
2.24
1.5
1.39
1.27
1.21
6.9 CCA-24HR1
MODEL
CCA-24HR1
HEATING
OUTDOOR CONDITIONS
Indoor Conditions
24ºC D
18ºC W
7ºC D
6ºC W
2ºC DB
1ºC WB
-5ºC D
-6ºC W
-7ºC D
-8ºC W
15ºC
Capacity kW
10.25
8.21
6.78
6.12
5.76
Input kW.
2.38
2.12
2.07
1.95
1.84
20ºC
Capacity kW
9.95
7.8
6.38
5.98
5.51
Input kW.
2.45
2.15
2.11
2.07
1.94
27ºC
Capacity kW
9.34
7.43
6.01
5.82
5.18
Input kW.
2.63
2.25
2.18
2.12
2.05
