Chigo CHV Mini Series - Page 28

CHV Mini VRF 50/60Hz
201908 27
Part 2 - Outdoor Units
CHV-DH100W/R1
TC: Total Capacity (kW); PI: Power Input (kW) (Compressor + Outdoor fan motor)
Combination
(%)
(Capacity
index)
Outdoor Air
temperature
(
°
C DB)
Indoor temperature (
°
C WB)
DB: 20.8, WB: 14 DB: 23.3, WB: 16 DB: 25.8, WB: 18 DB: 27, WB: 19 DB: 28.2, WB: 20 DB: 30.7, WB: 22 DB: 32, WB: 24
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
130%
-5 7.0 1.16 7.4 1.23 7.7 1.27 7.8 1.29 8.0 1.32 8.2 1.36 8.5 1.40
-2 6.9 1.17 7.3 1.24 7.5 1.28 7.7 1.31 7.8 1.33 8.1 1.37 8.3 1.41
0 6.8 1.19 7.2 1.25 7.4 1.29 7.5 1.32 7.7 1.35 7.9 1.38 8.1 1.42
2 6.6 1.20 7.0 1.27 7.2 1.31 7.4 1.33 7.5 1.36 7.7 1.40 8.0 1.44
4 6.5 1.21 6.9 1.28 7.1 1.32 7.2 1.35 7.4 1.37 7.6 1.41 7.8 1.45
6 6.4 1.22 6.7 1.29 7.0 1.33 7.1 1.36 7.2 1.39 7.4 1.43 7.7 1.47
8 6.3 1.24 6.6 1.30
6.8 1.35 7.0 1.37 7.1 1.40 7.3 1.44 7.5 1.48
10 8.4 1.64 8.8 1.73 9.1 1.79 9.3 1.82 9.5 1.86 9.8 1.91 10.1 1.97
12
8.2 1.71 8.7 1.80 8.9 1.86 9.1 1.90 9.3 1.94 9.6 1.99 9.9 2.05
14
8.1 1.78 8.5 1.88 8.8 1.94 8.9 1.98 9.1 2.02 9.4 2.08 9.7 2.13
16
7.9 1.85 8.3 1.96 8.6 2.02 8.8 2.06 8.9 2.10 9.2 2.16 9.5 2.22
18
9.2 2.08 9.7 2.19 10.0 2.26 10.2 2.31 10.4 2.35 10.7 2.42 11.0 2.49
20
9.0 2.10 9.5 2.21 9.8 2.28 10.0 2.33 10.2 2.38 10.5 2.45 10.8 2.52
21
8.8 2.12 9.3 2.24 9.6 2.31 9.8 2.35 10.0 2.40 10.3 2.47 10.6 2.54
23
8.6 2.14 9.1 2.26 9.4 2.33 9.6 2.38 9.8 2.43 10.1 2.50 10.4 2.57
25
8.5 2.16 8.9
2.28 9.2 2.35 9.4 2.40 9.6 2.45 9.9 2.52 10.2 2.59
27
10.4 2.70 11.0 2.85 11.4 2.94 11.6 3.00 11.8 3.06 12.2 3.15 12.5 3.24
29
10.2 2.72 10.8 2.88 11.1 2.97 11.4 3.03 11.6 3.09 11.9 3.18 12.3 3.27
31
10.0 2.75 10.6 2.91 10.9 3.00 11.1 3.06 11.4 3.12 11.7 3.21 12.0 3.30
33
9.8 2.78 10.4 2.93 10.7 3.03 10.9 3.09 11.1 3.15 11.5 3.24 11.8 3.34
35
9.6 2.81 10.2 2.96 10.5 3.06 10.7 3.12 10.9 3.18 11.2 3.28 11.6 3.37
37
9.4 2.82 10.0 2.98 10.3 3.07 10.5 3.14 10.7 3.20 11.0 3.29 11.3 3.39
39
9.0 2.77 9.5 2.92 9.8 3.01 10.0 3.07 10.2 3.13 10.5 3.23 10.8 3.32
41
8.5 2.71 9.0 2.86 9.3 2.95 9.5 3.01 9.7 3.07 9.9 3.16 10.2 3.25
43
8.1 2.66
8.5 2.80 8.8 2.89 9.0 2.95 9.2 3.01 9.4 3.10 9.7 3.19
45
7.7 2.58 8.1 2.72 8.4 2.81 8.5 2.86 8.7 2.92 9.0 3.01 9.2 3.09
48
7.3 2.45 7.7 2.58 8.0 2.67 8.1 2.72 8.3 2.77 8.5 2.86 8.8 2.94
50
6.9 2.25 7.3 2.38 7.6 2.45 7.7 2.50 7.9 2.55 8.1 2.63 8.3 2.70
52
6.6 2.07 7.0 2.19 7.2 2.26 7.3 2.30 7.5 2.35 7.7 2.42 7.9 2.49
55
6.3 1.91 6.6 2.01 6.8 2.08 7.0 2.12 7.1 2.16 7.3 2.22 7.5 2.29
120%
-5 6.9 1.15 7.3 1.22 7.5 1.25 7.7 1.28 7.8 1.31 8.1 1.34 8.3 1.38
-2 6.8 1.16 7.2 1.23 7.4 1.27 7.5 1.29 7.7 1.32 7.9 1.36 8.1 1.40
0 6.6 1.18 7.0 1.24 7.2 1.28 7.4 1.31 7.5 1.33 7.8 1.37 8.0 1.41
2 6.5 1.19 6.9 1.25 7.1 1.29 7.2 1.32 7.4 1.35 7.6 1.39 7.8 1.42
4 6.4 1.20 6.7 1.27 7.0 1.31 7.1 1.33 7.2 1.36 7.5 1.40 7.7 1.44
6 6.3 1.21 6.6 1.28 6.8 1.32 7.0 1.35 7.1 1.37 7.3 1.41 7.5 1.45
8 6.1 1.22 6.5 1.29 6.7 1.33 6.8 1.36 7.0 1.39 7.2 1.43 7.4 1.47
10 8.2 1.62 8.7 1.71 9.0 1.77 9.1 1.80 9.3 1.84 9.6 1.89 9.9 1.95
12
8.1 1.69 8.5 1.79 8.8 1.84 9.0 1.88 9.1 1.92 9.4 1.97 9.7 2.03
14
7.9 1.76 8.3 1.86 8.6 1.92 8.8 1.96 9.0 2.00 9.2 2.06 9.5 2.11
16
7.7 1.84 8.2 1.94 8.4 2.00 8.6 2.04 8.8 2.08 9.0 2.14 9.3 2.20
18
9.0 2.06 9.5 2.17 9.8 2.24 10.0 2.29 10.2 2.33 10.5 2.40 10.8
2.47
20
8.8 2.08 9.3 2.19 9.6 2.26 9.8 2.31 10.0 2.35 10.3 2.42 10.6 2.49
21
8.7 2.10 9.1 2.22 9.4 2.29 9.6 2.33 9.8 2.38 10.1 2.45 10.4 2.52
23
8.5 2.12 9.0 2.24 9.2 2.31 9.4 2.36 9.6 2.40 9.9 2.47 10.2 2.54
25
8.3 2.14 8.8 2.26 9.1 2.33 9.2 2.38 9.4 2.43 9.7 2.50 10.0 2.57
27
10.2 2.67 10.8 2.82 11.1 2.91 11.4 2.97 11.6 3.03 11.9 3.12 12.3 3.21
29
10.0 2.70 10.6 2.85 10.9 2.94 11.1 3.00 11.4 3.06 11.7 3.15 12.0 3.24
31
9.8 2.73 10.4 2.88 10.7 2.97 10.9 3.03 11.1 3.09 11.5 3.18 11.8 3.27
33
9.6 2.75 10.2 2.91 10.5 3.00 10.7 3.06 10.9 3.12 11.2 3.21 11.6 3.30
35
9.5 2.78 10.0 2.94 10.3 3.03 10.5 3.09 10.7 3.15 11.0 3.24
11.3 3.34
37
9.3 2.79 9.8 2.95 10.1 3.04 10.3 3.11 10.5 3.17 10.8 3.26 11.1 3.35
39
8.8 2.74 9.3 2.89 9.6 2.98 9.8 3.04 10.0 3.10 10.3 3.20 10.6 3.29
41
8.4 2.68 8.8 2.83 9.1 2.92 9.3 2.98 9.5 3.04 9.8 3.13 10.0 3.22
43
7.9 2.63 8.4 2.78 8.6 2.86 8.8 2.92 9.0 2.98 9.3 3.07 9.5 3.16
45
7.5 2.55 8.0 2.69 8.2 2.78 8.4 2.84 8.5 2.89 8.8 2.98 9.1 3.06
48
7.2 2.42 7.6 2.56 7.8 2.64 8.0 2.69 8.1 2.75 8.4 2.83 8.6 2.91
50
6.8 2.23 7.2 2.35 7.4 2.43 7.6 2.48 7.7 2.53 7.9 2.60 8.2 2.68
52
6.5 2.05 6.8 2.17 7.0 2.23 7.2 2.28 7.3 2.33 7.5 2.39 7.8 2.46
55
6.1 1.89 6.5 1.99 6.7 2.06 6.8 2.10 7.0 2.14 7.2
2.20 7.4 2.27
