CHV Mini VRF 50/60Hz
28 201908
CHV Mini Series Service Manual
Combination
(%)
(Capacity
index)
Outdoor Air
temperature
(
°
C DB)
Indoor temperature (
°
C WB)
DB: 20.8, WB: 14 DB: 23.3, WB: 16 DB: 25.8, WB: 18 DB: 27, WB: 19 DB: 28.2, WB: 20 DB: 30.7, WB: 22 DB: 32, WB: 24
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
110%
-5 6.8 1.14 7.2 1.20 7.4 1.24 7.5 1.27 7.7 1.29 7.9 1.33 8.1 1.37
-2 6.7 1.15 7.0 1.22 7.2 1.25 7.4 1.28 7.5 1.31 7.8 1.34 8.0 1.38
0 6.5 1.16 6.9 1.23 7.1 1.27 7.2 1.29 7.4 1.32 7.6 1.36 7.8 1.40
2 6.4 1.18 6.7 1.24 7.0 1.28 7.1 1.31 7.2 1.33 7.5 1.37 7.7 1.41
4 6.3 1.19 6.6 1.25 6.8 1.29 7.0 1.32 7.1 1.35 7.3 1.39 7.5 1.43
6 6.1 1.20 6.5 1.27 6.7 1.31 6.8 1.33 7.0 1.36 7.2 1.40 7.4 1.44
8 6.0 1.21 6.4 1.28
6.6 1.32 6.7 1.35 6.8 1.37 7.0 1.41 7.2 1.45
10 8.1 1.61 8.5 1.70 8.8 1.75 9.0 1.79 9.1 1.82 9.4 1.88 9.7 1.93
12
7.9 1.68 8.3 1.77 8.6 1.82 8.8 1.86 9.0 1.90 9.2 1.95 9.5 2.01
14
7.8 1.74 8.2 1.84 8.4 1.90 8.6 1.94 8.8 1.98 9.0 2.04 9.3 2.09
16
7.6 1.82 8.0 1.92 8.3 1.98 8.4 2.02 8.6 2.06 8.9 2.12 9.1 2.18
18
8.8 2.04 9.3 2.15 9.6 2.22 9.8 2.26 10.0 2.31 10.3 2.38 10.6 2.44
20
8.7 2.06 9.1 2.17 9.4 2.24 9.6 2.29 9.8 2.33 10.1 2.40 10.4 2.47
21
8.5 2.08 9.0 2.19 9.2 2.26 9.4 2.31 9.6 2.36 9.9 2.42 10.2 2.49
23
8.3 2.10 8.8 2.22 9.1 2.29 9.2 2.33 9.4 2.38 9.7 2.45 10.0 2.52
25
8.2 2.12 8.6
2.24 8.9 2.31 9.1 2.36 9.2 2.40 9.5 2.47 9.8 2.54
27
10.0 2.65 10.6 2.79 10.9 2.88 11.1 2.94 11.4 3.00 11.7 3.09 12.0 3.17
29
9.8 2.67 10.4 2.82 10.7 2.91 10.9 2.97 11.1 3.03 11.5 3.12 11.8 3.21
31
9.6 2.70 10.2 2.85 10.5 2.94 10.7 3.00 10.9 3.06 11.3 3.15 11.6 3.24
33
9.5 2.73 10.0 2.88 10.3 2.97 10.5 3.03 10.7 3.09 11.0 3.18 11.3 3.27
35
9.3 2.75 9.8 2.91 10.1 3.00 10.3 3.06 10.5 3.12 10.8 3.21 11.1 3.30
37
9.1 2.77 9.6 2.92 9.9 3.01 10.1 3.08 10.3 3.14 10.6 3.23 10.9 3.32
39
8.6 2.71 9.1 2.86 9.4 2.95 9.6 3.01 9.8 3.07 10.1 3.16 10.4 3.25
41
8.2 2.66 8.7 2.81 8.9 2.89 9.1 2.95 9.3 3.01 9.6 3.10 9.8 3.19
43
7.8 2.61
8.2 2.75 8.5 2.84 8.7 2.89 8.8 2.95 9.1 3.04 9.3 3.13
45
7.4 2.53 7.8 2.67 8.1 2.75 8.2 2.81 8.4 2.86 8.6 2.95 8.9 3.03
48
7.0 2.40 7.4 2.53 7.7 2.61 7.8 2.67 8.0 2.72 8.2 2.80 8.4 2.88
50
6.7 2.21 7.0 2.33 7.3 2.40 7.4 2.45 7.6 2.50 7.8 2.58 8.0 2.65
52
6.3 2.03 6.7 2.14 6.9 2.21 7.0 2.26 7.2 2.30 7.4 2.37 7.6 2.44
55
6.0 1.87 6.4 1.97 6.6 2.04 6.7 2.08 6.8 2.12 7.0 2.18 7.2 2.24
100%
-5 6.6 1.12 7.0 1.18 7.2 1.22 7.3 1.24 7.5 1.27 7.7 1.30 7.9 1.34
-2 6.5 1.13 6.8 1.19 7.0 1.23 7.2 1.26 7.3 1.28 7.5 1.32 7.8 1.36
0 6.3 1.14 6.7 1.20 6.9 1.24 7.0 1.27 7.2 1.29 7.4 1.33 7.6 1.37
2 6.2 1.15 6.6 1.22 6.8 1.26 6.9 1.28 7.0 1.31 7.2 1.34 7.4 1.38
4 6.1 1.16 6.4 1.23 6.6 1.27 6.8 1.29 6.9 1.32 7.1 1.36 7.3 1.40
6 6.0 1.18 6.3 1.24 6.5 1.28 6.6 1.31 6.8 1.33 7.0 1.37 7.2 1.41
8 5.9 1.19 6.2 1.25 6.4 1.29 6.5 1.32 6.6 1.35 6.8 1.39 7.0 1.43
10 7.8 1.58 8.3 1.66 8.5 1.72 8.7 1.75 8.9 1.79 9.1 1.84 9.4 1.89
12
7.7 1.64 8.1 1.73 8.4 1.79 8.5 1.82 8.7 1.86 9.0 1.92 9.2 1.97
14
7.5 1.71 7.9 1.81 8.2 1.86 8.4 1.90 8.5 1.94 8.8 2.00 9.0 2.05
16
7.4 1.78 7.8 1.88 8.0 1.94 8.2 1.98 8.4 2.02 8.6 2.08 8.9 2.14
18
8.6 2.00 9.0 2.11 9.3 2.17 9.5 2.22 9.7 2.26 10.0 2.33 10.3
2.40
20
8.4 2.02 8.9 2.13 9.2 2.20 9.3 2.24 9.5 2.29 9.8 2.35 10.1 2.42
21
8.2 2.04 8.7 2.15 9.0 2.22 9.2 2.26 9.3 2.31 9.6 2.38 9.9 2.45
23
8.1 2.06 8.5 2.17 8.8 2.24 9.0 2.29 9.2 2.33 9.4 2.40 9.7 2.47
25
7.9 2.08 8.4 2.19 8.6 2.26 8.8 2.31 9.0 2.36 9.2 2.43 9.5 2.49
27
9.7 2.59 10.3 2.74 10.6 2.82 10.8 2.88 11.0 2.94 11.4 3.03 11.7 3.11
29
9.6 2.62 10.1 2.77 10.4 2.85 10.6 2.91 10.8 2.97 11.1 3.06 11.5 3.14
31
9.4 2.65 9.9 2.79 10.2 2.88 10.4 2.94 10.6 3.00 10.9 3.09 11.2 3.18
33
9.2 2.67 9.7 2.82 10.0 2.91 10.2 2.97 10.4 3.03 10.7 3.12 11.0 3.21
35
9.0 2.70 9.5 2.85 9.8 2.94 10.0 3.00 10.2 3.06 10.5 3.15
10.8 3.24
37
8.8 2.71 9.3 2.86 9.6 2.95 9.8 3.05 10.0 3.08 10.3 3.17 10.6 3.26
39
8.4 2.66 8.8 2.81 9.1 2.90 9.6 3.10 9.5 3.01 9.8 3.10 10.1 3.19
41
8.0 2.61 8.4 2.75 8.7 2.84 9.4 3.15 9.0 2.95 9.3 3.04 9.6 3.13
43
7.6 2.55 8.0 2.70 8.2 2.78 9.2 3.20 8.6 2.89 8.8 2.98 9.1 3.06
45
7.2 2.48 7.6 2.61 7.8 2.70 9.0 3.25 8.1 2.81 8.4 2.89 8.6 2.97
48
6.8 2.35 7.2 2.48 7.4 2.56 8.9 3.30 7.7 2.67 8.0 2.75 8.2 2.82
50
6.5 2.17 6.8 2.29 7.1 2.36 8.7 3.35 7.3 2.45 7.6 2.53 7.8 2.60
52
6.2 1.99 6.5 2.10 6.7 2.17 8.5 3.41 7.0 2.26 7.2 2.32 7.4 2.39
55
5.9 1.83 6.2 1.93 6.4 2.00 8.3 3.46 6.6 2.08 6.8
2.14 7.0 2.20
