Chigo CHV Mini Series - Page 35

CHV Mini VRF 50/60Hz
34 201908
CHV Mini Series Service Manual
Combination
(%)
(Capacity
index)
Outdoor Air
temperature
(
°
C DB)
Indoor temperature (
°
C WB)
DB: 20.8, WB: 14 DB: 23.3, WB: 16 DB: 25.8, WB: 18 DB: 27, WB: 19 DB: 28.2, WB: 20 DB: 30.7, WB: 22 DB: 32, WB: 24
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
90%
-5 7.8 1.12 8.3 1.18 8.5 1.22 8.7 1.25 8.9 1.27 9.1 1.31 9.4 1.35
-2 7.7 1.13 8.1 1.20 8.4 1.23 8.5 1.26 8.7 1.28 8.9 1.32 9.2 1.36
0 7.5 1.14 7.9 1.21 8.2 1.25 8.4 1.27 8.5 1.30 8.8 1.33 9.0 1.37
2 7.4 1.16 7.8 1.22 8.0 1.26 8.2 1.28 8.4 1.31 8.6 1.35 8.8 1.39
4 7.2 1.17 7.6 1.23 7.9 1.27 8.0 1.30 8.2 1.32 8.4 1.36 8.7 1.40
6 7.1 1.18 7.5 1.24 7.7 1.28 7.9 1.31 8.0 1.34 8.3 1.38 8.5 1.42
8 6.9 1.19 7.3 1.26
7.6 1.30 7.7 1.32 7.9 1.35 8.1 1.39 8.3 1.43
10 9.3 1.58 9.8 1.67 10.1 1.72 10.3 1.76 10.5 1.79 10.9 1.84 11.2 1.90
12
9.1 1.65 9.6 1.74 9.9 1.79 10.1 1.83 10.3 1.87 10.6 1.92 10.9 1.98
14
8.9 1.72 9.4 1.81 9.7 1.87 9.9 1.91 10.1 1.94 10.4 2.00 10.7 2.06
16
8.8 1.79 9.3 1.89 9.5 1.95 9.7 1.99 9.9 2.02 10.2 2.08 10.5 2.14
18
10.2 2.00 10.7 2.11 11.1 2.18 11.3 2.22 11.5 2.27 11.9 2.34 12.2 2.40
20
10.0 2.02 10.5 2.13 10.9 2.20 11.1 2.25 11.3 2.29 11.6 2.36 12.0 2.43
21
9.8 2.04 10.3 2.16 10.7 2.22 10.9 2.27 11.1 2.32 11.4 2.38 11.7 2.45
23
9.6 2.06 10.1 2.18 10.4 2.25 10.7 2.29 10.9 2.34 11.2 2.41 11.5 2.48
25
9.4 2.08 9.9
2.20 10.2 2.27 10.5 2.32 10.7 2.36 11.0 2.43 11.3 2.50
27
11.6 2.60 12.2 2.74 12.6 2.83 12.9 2.89 13.1 2.95 13.5 3.03 13.9 3.12
29
11.3 2.63 12.0 2.77 12.3 2.86 12.6 2.92 12.9 2.98 13.2 3.06 13.6 3.15
31
11.1 2.65 11.7 2.80 12.1 2.89 12.4 2.95 12.6 3.01 13.0 3.10 13.3 3.18
33
10.9 2.68 11.5 2.83 11.9 2.92 12.1 2.98 12.4 3.04 12.7 3.13 13.1 3.22
35
10.7 2.71 11.3 2.86 11.6 2.95 11.9 3.01 12.1 3.07 12.5 3.16 12.8 3.25
37
10.5 2.72 11.1 2.87 11.4 2.96 11.6 3.02 11.9 3.08 12.2 3.17 12.6 3.26
39
10.0 2.67 10.5 2.81 10.8 2.90 11.1 2.96 11.3 3.02 11.6 3.11 11.9 3.20
41
9.5 2.61 10.0 2.76 10.3 2.85 10.5 2.90 10.7 2.96 11.0 3.05 11.3 3.14
43
9.0 2.56
9.5 2.70 9.8 2.79 10.0 2.85 10.2 2.90 10.5 2.99 10.8 3.07
45
8.5 2.48 9.0 2.62 9.3 2.70 9.5 2.76 9.7 2.82 10.0 2.90 10.2 2.98
48
8.1 2.36 8.6 2.49 8.8 2.57 9.0 2.62 9.2 2.67 9.5 2.75 9.7 2.83
50
7.7 2.17 8.1 2.29 8.4 2.36 8.6 2.41 8.7 2.46 9.0 2.53 9.2 2.61
52
7.3 2.00 7.7 2.11 8.0 2.17 8.1 2.22 8.3 2.26 8.5 2.33 8.8 2.40
55
6.9 1.84 7.3 1.94 7.6 2.00 7.7 2.04 7.9 2.08 8.1 2.14 8.3 2.20
80%
-5 7.1 1.01 7.5 1.07 7.7 1.10 7.9 1.13 8.0 1.15 8.3 1.18 8.5 1.22
-2 6.9 1.02 7.3 1.08 7.6 1.12 7.7 1.14 7.9 1.16 8.1 1.20 8.3 1.23
0 6.8 1.03 7.2 1.09 7.4 1.13 7.6 1.15 7.7 1.17 7.9 1.21 8.2 1.24
2 6.7 1.05 7.0 1.10 7.3 1.14 7.4 1.16 7.6 1.18 7.8 1.22 8.0 1.25
4 6.5 1.06 6.9 1.11 7.1 1.15 7.3 1.17 7.4 1.20 7.6 1.23 7.9 1.27
6 6.4 1.07 6.8 1.13 7.0 1.16 7.1 1.18 7.3 1.21 7.5 1.24 7.7 1.28
8 6.3 1.08 6.6 1.14 6.8 1.17 7.0 1.20 7.1 1.22 7.3 1.26 7.5 1.29
10 8.4 1.43 8.9 1.51 9.2 1.56 9.4 1.59 9.5 1.62 9.8 1.67 10.1 1.72
12
8.3 1.49 8.7 1.57 9.0 1.62 9.2 1.65 9.4 1.69 9.6 1.74 9.9 1.79
14
8.1 1.55 8.5 1.64 8.8 1.69 9.0 1.72 9.2 1.76 9.4 1.81 9.7 1.86
16
7.9 1.62 8.4 1.71 8.6 1.76 8.8 1.80 9.0 1.83 9.3 1.88 9.5 1.94
18
9.2 1.81 9.7 1.91 10.0 1.97 10.2 2.01 10.4 2.05 10.8 2.11 11.1
2.17
20
9.0 1.83 9.5 1.93 9.8 1.99 10.0 2.03 10.2 2.07 10.5 2.13 10.8 2.19
21
8.9 1.85 9.4 1.95 9.6 2.01 9.8 2.05 10.0 2.09 10.3 2.16 10.6 2.22
23
8.7 1.87 9.2 1.97 9.5 2.03 9.6 2.07 9.8 2.11 10.1 2.18 10.4 2.24
25
8.5 1.88 9.0 1.99 9.3 2.05 9.5 2.09 9.6 2.14 9.9 2.20 10.2 2.26
27
10.5 2.35 11.1 2.48 11.4 2.56 11.6 2.61 11.9 2.67 12.2 2.74 12.6 2.82
29
10.3 2.38 10.8 2.51 11.2 2.59 11.4 2.64 11.6 2.69 12.0 2.77 12.3 2.85
31
10.1 2.40 10.6 2.53 11.0 2.61 11.2 2.67 11.4 2.72 11.7 2.80 12.1 2.88
33
9.9 2.42 10.4 2.56 10.7 2.64 11.0 2.69 11.2 2.75 11.5 2.83 11.8 2.91
35
9.7 2.45 10.2 2.58 10.5 2.67 10.8 2.72 11.0 2.77 11.3 2.86
11.6 2.94
37
9.5 2.46 10.0 2.60 10.3 2.68 10.5 2.73 10.7 2.79 11.1 2.87 11.4 2.95
39
9.0 2.41 9.5 2.54 9.8 2.63 10.0 2.68 10.2 2.73 10.5 2.81 10.8 2.89
41
8.6 2.36 9.0 2.49 9.3 2.57 9.5 2.63 9.7 2.68 10.0 2.76 10.3 2.84
43
8.1 2.32 8.6 2.44 8.9 2.52 9.0 2.57 9.2 2.62 9.5 2.70 9.8 2.78
45
7.7 2.25 8.2 2.37 8.4 2.45 8.6 2.50 8.8 2.55 9.0 2.62 9.3 2.70
48
7.3 2.13 7.7 2.25 8.0 2.32 8.2 2.37 8.3 2.42 8.6 2.49 8.8 2.56
50
7.0 1.96 7.4 2.07 7.6 2.14 7.7 2.18 7.9 2.22 8.1 2.29 8.4 2.36
52
6.6 1.81 7.0 1.91 7.2 1.97 7.4 2.01 7.5 2.05 7.7 2.11 7.9 2.17
55
6.3 1.66 6.6 1.75 6.8 1.81 7.0 1.85 7.1 1.88 7.3
1.94 7.5 1.99
