Chigo CHV Mini Series - Page 36

Combination
(%)
(Capacity
index)
Outdoor Air
temperature
(
°
C DB)
Indoor temperature (
°
C WB)
DB: 20.8, WB: 14 DB: 23.3, WB: 16 DB: 25.8, WB: 18 DB: 27, WB: 19 DB: 28.2, WB: 20 DB: 30.7, WB: 22 DB: 32, WB: 24
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
70%
-5 6.3 0.91 6.7 0.96 6.9 0.99 7.0 1.01 7.2 1.03 7.4 1.06 7.6 1.09
-2 6.2 0.92 6.6 0.97 6.8 1.00 6.9 1.02 7.0 1.04 7.3 1.07 7.5 1.10
0 6.1 0.93 6.4 0.98 6.6 1.01 6.8 1.03 6.9 1.05 7.1 1.08 7.3 1.11
2 6.0 0.93 6.3 0.99 6.5 1.02 6.6 1.04 6.8 1.06 7.0 1.09 7.2 1.12
4 5.9 0.94 6.2 1.00 6.4 1.03 6.5 1.05 6.6 1.07 6.8 1.10 7.0 1.13
6 5.7 0.95 6.1 1.01 6.3 1.04 6.4 1.06 6.5 1.08 6.7 1.11 6.9 1.14
8 5.6 0.96 5.9 1.02
6.1 1.05 6.3 1.07 6.4 1.09 6.6 1.12 6.8 1.16
10 7.5 1.28 8.0 1.35 8.2 1.39 8.4 1.42 8.5 1.45 8.8 1.49 9.0 1.53
12
7.4 1.33 7.8 1.41 8.0 1.45 8.2 1.48 8.4 1.51 8.6 1.55 8.9 1.60
14
7.2 1.39 7.6 1.46 7.9 1.51 8.1 1.54 8.2 1.57 8.5 1.62 8.7 1.66
16
7.1 1.44 7.5 1.52 7.7 1.57 7.9 1.61 8.1 1.64 8.3 1.69 8.5 1.73
18
8.3 1.62 8.7 1.71 9.0 1.76 9.2 1.80 9.4 1.83 9.6 1.89 9.9 1.94
20
8.1 1.64 8.5 1.73 8.8 1.78 9.0 1.82 9.2 1.85 9.4 1.91 9.7 1.96
21
7.9 1.65 8.4 1.74 8.6 1.80 8.8 1.84 9.0 1.87 9.3 1.93 9.5 1.98
23
7.8 1.67 8.2 1.76 8.5 1.82 8.6 1.85 8.8 1.89 9.1 1.95 9.3 2.00
25
7.6 1.69 8.0
1.78 8.3 1.84 8.5 1.87 8.6 1.91 8.9 1.97 9.1 2.02
27
9.4 2.10 9.9 2.22 10.2 2.29 10.4 2.34 10.6 2.38 10.9 2.45 11.3 2.52
29
9.2 2.12 9.7 2.24 10.0 2.31 10.2 2.36 10.4 2.41 10.7 2.48 11.0 2.55
31
9.0 2.15 9.5 2.26 9.8 2.34 10.0 2.38 10.2 2.43 10.5 2.50 10.8 2.57
33
8.8 2.17 9.3 2.29 9.6 2.36 9.8 2.41 10.0 2.46 10.3 2.53 10.6 2.60
35
8.7 2.19 9.1 2.31 9.4 2.38 9.6 2.43 9.8 2.48 10.1 2.55 10.4 2.63
37
8.5 2.20 9.0 2.32 9.2 2.40 9.4 2.44 9.6 2.49 9.9 2.57 10.2 2.64
39
8.3 2.21 8.8 2.33 9.1 2.41 9.2 2.46 9.4 2.51 9.7 2.58 10.0 2.65
41
8.2 2.22 8.6 2.35 8.9 2.42 9.1 2.47 9.2 2.52 9.5 2.59 9.8 2.67
43
8.0 2.23
8.4 2.36 8.7 2.43 8.9 2.48 9.1 2.53 9.3 2.61 9.6 2.68
45
7.8 2.24 8.3 2.37 8.5 2.44 8.7 2.49 8.9 2.54 9.1 2.62 9.4 2.69
48
7.7 2.26 8.1 2.38 8.4 2.46 8.5 2.51 8.7 2.56 9.0 2.63 9.2 2.71
50
7.5 2.27 7.9 2.39 8.2 2.47 8.4 2.52 8.5 2.57 8.8 2.64 9.0 2.72
52
7.4 2.28 7.8 2.40 8.0 2.48 8.2 2.53 8.4 2.58 8.6 2.66 8.8 2.73
55
7.2 2.29 7.6 2.42 7.9 2.49 8.0 2.54 8.2 2.59 8.4 2.67 8.7 2.75
60%
-5 5.6 0.80 5.9 0.84 6.1 0.87 6.2 0.89 6.3 0.91 6.5 0.93 6.7 0.96
-2 5.5 0.81 5.8 0.85 6.0 0.88 6.1 0.90 6.2 0.92 6.4 0.94 6.6 0.97
0 5.4 0.82 5.7 0.86 5.9 0.89 6.0 0.91 6.1 0.92 6.3 0.95 6.5 0.98
2 5.3 0.82 5.6 0.87 5.7 0.90 5.9 0.92 6.0 0.93 6.2 0.96 6.3 0.99
4 5.2 0.83 5.5 0.88 5.6 0.91 5.7 0.92 5.9 0.94 6.0 0.97 6.2 1.00
6 5.1 0.84 5.4 0.89 5.5 0.92 5.6 0.93 5.7 0.95 5.9 0.98 6.1 1.01
8 5.0 0.85 5.2 0.90 5.4 0.92 5.5 0.94 5.6 0.96 5.8 0.99 6.0 1.02
10 6.7 1.13 7.0 1.19 7.2 1.23 7.4 1.25 7.5 1.28 7.8 1.31 8.0 1.35
12
6.5 1.17 6.9 1.24 7.1 1.28 7.3 1.30 7.4 1.33 7.6 1.37 7.8 1.41
14
6.4 1.22 6.8 1.29 7.0 1.33 7.1 1.36 7.3 1.39 7.5 1.43 7.7 1.47
16
6.3 1.27 6.6 1.34 6.8 1.39 7.0 1.42 7.1 1.44 7.3 1.49 7.5 1.53
18
7.3 1.43 7.7 1.51 7.9 1.55 8.1 1.59 8.3 1.62 8.5 1.67 8.7
1.71
20
7.1 1.44 7.5 1.52 7.8 1.57 7.9 1.60 8.1 1.63 8.3 1.68 8.6 1.73
21
7.0 1.46 7.4 1.54 7.6 1.59 7.8 1.62 7.9 1.65 8.2 1.70 8.4 1.75
23
6.9 1.47 7.2 1.55 7.5 1.60 7.6 1.63 7.8 1.67 8.0 1.72 8.2 1.77
25
6.7 1.49 7.1 1.57 7.3 1.62 7.5 1.65 7.6 1.68 7.9 1.73 8.1 1.78
27
8.3 1.85 8.7 1.96 9.0 2.02 9.2 2.06 9.4 2.10 9.7 2.16 9.9 2.22
29
8.1 1.87 8.6 1.98 8.8 2.04 9.0 2.08 9.2 2.12 9.5 2.18 9.7 2.25
31
8.0 1.89 8.4 2.00 8.7 2.06 8.8 2.10 9.0 2.14 9.3 2.21 9.6 2.27
33
7.8 1.91 8.2 2.02 8.5 2.08 8.7 2.12 8.8 2.17 9.1 2.23 9.4 2.29
35
7.7 1.93 8.1 2.04 8.3 2.10 8.5 2.14 8.7 2.19 8.9 2.25
9.2 2.32
37
7.5 1.94 7.9 2.05 8.2 2.11 8.3 2.15 8.5 2.20 8.7 2.26 9.0 2.33
39
7.3 1.95 7.8 2.06 8.0 2.12 8.2 2.17 8.3 2.21 8.6 2.27 8.8 2.34
41
7.2 1.96 7.6 2.07 7.8 2.13 8.0 2.18 8.2 2.22 8.4 2.29 8.6 2.35
43
7.1 1.97 7.4 2.08 7.7 2.14 7.8 2.19 8.0 2.23 8.2 2.30 8.5 2.36
45
6.9 1.98 7.3 2.09 7.5 2.15 7.7 2.20 7.8 2.24 8.1 2.31 8.3 2.37
48
6.8 1.99 7.2 2.10 7.4 2.16 7.5 2.21 7.7 2.25 7.9 2.32 8.1 2.39
50
6.6 2.00 7.0 2.11 7.2 2.18 7.4 2.22 7.5 2.26 7.7 2.33 8.0 2.40
52
6.5 2.01 6.9 2.12 7.1 2.19 7.2 2.23 7.4 2.28 7.6 2.34 7.8 2.41
55
6.4 2.02 6.7 2.13 6.9 2.20 7.1 2.24 7.2 2.29 7.4
2.35 7.7 2.42
