CHV Mini VRF 50/60Hz
201908 37
Part 2 - Outdoor Units
CHV-DH140W/R1
TC: Total Capacity (kW); PI: Power Input (kW) (Compressor + Outdoor fan motor)
Combination
(%)
(Capacity
index)
Outdoor Air
temperature
(
°
C DB)
Indoor temperature (
°
C WB)
DB: 20.8, WB: 14 DB: 23.3, WB: 16 DB: 25.8, WB: 18 DB: 27, WB: 19 DB: 28.2, WB: 20 DB: 30.7, WB: 22 DB: 32, WB: 24
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
130%
-5 9.9 1.45 10.4 1.53 10.7 1.58 11.0 1.62 11.2 1.65 11.5 1.70 11.8 1.74
-2 9.7 1.47 10.2 1.55 10.5 1.60 10.8 1.63 11.0 1.66 11.3 1.71 11.6 1.76
0 9.5 1.48 10.0 1.57 10.3 1.62 10.5 1.65 10.8 1.68 11.1 1.73 11.4 1.78
2 9.3 1.50 9.8 1.58 10.1 1.63 10.3 1.67 10.5 1.70 10.8 1.75 11.2 1.80
4 9.1 1.51 9.6 1.60 9.9 1.65 10.1 1.68 10.3 1.72 10.6 1.77 10.9 1.82
6 8.9 1.53 9.4 1.61 9.7 1.66 9.9 1.70 10.1 1.73 10.4 1.78 10.7 1.83
8 8.8 1.54 9.3 1.63
9.5 1.68 9.7 1.72 9.9 1.75 10.2 1.80 10.5 1.85
10 11.7 2.05 12.4 2.16 12.8 2.23 13.0 2.28 13.3 2.32 13.7 2.39 14.1 2.46
12
11.5 2.13 12.1 2.25 12.5 2.32 12.8 2.37 13.0 2.42 13.4 2.49 13.8 2.56
14
11.3 2.22 11.9 2.35 12.3 2.42 12.5 2.47 12.8 2.52 13.2 2.59 13.5 2.67
16
11.1 2.32 11.7 2.45 12.0 2.52 12.3 2.57 12.5 2.63 12.9 2.70 13.3 2.78
18
12.8 2.60 13.6 2.74 14.0 2.83 14.3 2.88 14.6 2.94 15.0 3.03 15.4 3.12
20
12.6 2.62 13.3 2.77 13.7 2.86 14.0 2.91 14.3 2.97 14.7 3.06 15.1 3.15
21
12.3 2.65 13.0 2.80 13.4 2.88 13.7 2.94 14.0 3.00 14.4 3.09 14.8 3.18
23
12.1 2.68 12.8 2.82 13.2 2.91 13.4 2.97 13.7 3.03 14.1 3.12 14.5 3.21
25
11.9 2.70 12.5
2.85 12.9 2.94 13.2 3.00 13.4 3.06 13.8 3.15 14.2 3.24
27
14.6 3.37 15.4 3.56 15.9 3.67 16.2 3.75 16.5 3.82 17.0 3.93 17.5 4.05
29
14.3 3.41 15.1 3.59 15.6 3.71 15.9 3.78 16.2 3.86 16.7 3.97 17.2 4.09
31
14.0 3.44 14.8 3.63 15.3 3.75 15.6 3.82 15.9 3.90 16.4 4.01 16.8 4.13
33
13.8 3.47 14.5 3.67 15.0 3.78 15.3 3.86 15.6 3.94 16.0 4.05 16.5 4.17
35
13.5 3.51 14.2 3.71 14.7 3.82 15.0 3.90 15.3 3.98 15.7 4.10 16.2 4.21
37
13.2 3.53 13.9 3.72 14.4 3.84 14.7 3.92 15.0 4.00 15.4 4.12 15.9 4.23
39
12.6 3.46 13.2 3.65 13.7 3.76 13.9 3.84 14.2 3.92 14.6 4.03 15.1 4.15
41
11.9 3.39 12.6 3.58 13.0 3.69 13.2 3.76 13.5 3.84 13.9 3.95 14.3 4.07
43
11.3 3.32
12.0 3.50 12.3 3.62 12.6 3.69 12.8 3.76 13.2 3.87 13.6 3.98
45
10.8 3.22 11.4 3.40 11.7 3.51 12.0 3.58 12.2 3.65 12.6 3.76 12.9 3.86
48
10.2 3.06 10.8 3.23 11.1 3.33 11.4 3.40 11.6 3.47 11.9 3.57 12.3 3.67
50
9.7 2.81 10.3 2.97 10.6 3.06 10.8 3.13 11.0 3.19 11.3 3.28 11.7 3.38
52
9.2 2.59 9.7 2.73 10.0 2.82 10.3 2.88 10.5 2.93 10.8 3.02 11.1 3.11
55
8.8 2.38 9.3 2.51 9.5 2.59 9.7 2.65 9.9 2.70 10.2 2.78 10.5 2.86
120%
-5 9.7 1.44 10.2 1.52 10.5 1.57 10.8 1.60 11.0 1.63 11.3 1.68 11.6 1.73
-2 9.5 1.45 10.0 1.54 10.3 1.58 10.5 1.62 10.8 1.65 11.1 1.70 11.4 1.75
0 9.3 1.47 9.8 1.55 10.1 1.60 10.3 1.63 10.5 1.67 10.9 1.71 11.2 1.76
2 9.1 1.48 9.6 1.57 9.9 1.62 10.1 1.65 10.3 1.68 10.6 1.73 11.0 1.78
4 8.9 1.50 9.4 1.58 9.7 1.63 9.9 1.67 10.1 1.70 10.4 1.75 10.7 1.80
6 8.8 1.51 9.3 1.60 9.6 1.65 9.7 1.68 9.9 1.72 10.2 1.77 10.5 1.82
8 8.6 1.53 9.1 1.61 9.4 1.67 9.6 1.70 9.7 1.73 10.0 1.78 10.3 1.84
10 11.5 2.03 12.2 2.14 12.5 2.21 12.8 2.26 13.0 2.30 13.4 2.37 13.8 2.44
12
11.3 2.11 11.9 2.23 12.3 2.30 12.5 2.35 12.8 2.40 13.2 2.47 13.5 2.54
14
11.1 2.20 11.7 2.32 12.0 2.40 12.3 2.45 12.5 2.50 12.9 2.57 13.3 2.64
16
10.8 2.29 11.5 2.42 11.8 2.50 12.1 2.55 12.3 2.60 12.7 2.68 13.0 2.75
18
12.6 2.57 13.3 2.71 13.7 2.80 14.0 2.86 14.3 2.91 14.7 3.00 15.1
3.09
20
12.4 2.60 13.0 2.74 13.5 2.83 13.7 2.89 14.0 2.94 14.4 3.03 14.8 3.12
21
12.1 2.62 12.8 2.77 13.2 2.86 13.5 2.91 13.7 2.97 14.1 3.06 14.5 3.15
23
11.9 2.65 12.5 2.80 12.9 2.89 13.2 2.94 13.5 3.00 13.9 3.09 14.3 3.18
25
11.6 2.68 12.3 2.83 12.7 2.91 12.9 2.97 13.2 3.03 13.6 3.12 14.0 3.21
27
14.3 3.34 15.1 3.52 15.6 3.64 15.9 3.71 16.2 3.78 16.7 3.90 17.2 4.01
29
14.0 3.37 14.8 3.56 15.3 3.67 15.6 3.75 15.9 3.82 16.4 3.94 16.8 4.05
31
13.8 3.41 14.5 3.60 15.0 3.71 15.3 3.79 15.6 3.86 16.1 3.97 16.5 4.09
33
13.5 3.44 14.2 3.63 14.7 3.75 15.0 3.82 15.3 3.90 15.7 4.02 16.2 4.13
35
13.2 3.48 14.0 3.67 14.4 3.79 14.7 3.86 15.0 3.94 15.4 4.06
15.9 4.17
37
13.0 3.49 13.7 3.69 14.1 3.80 14.4 3.88 14.7 3.96 15.1 4.08 15.6 4.19
39
12.3 3.42 13.0 3.61 13.4 3.73 13.7 3.80 14.0 3.88 14.4 3.99 14.8 4.11
41
11.7 3.36 12.4 3.54 12.7 3.65 13.0 3.73 13.3 3.80 13.7 3.91 14.0 4.03
43
11.1 3.29 11.7 3.47 12.1 3.58 12.4 3.65 12.6 3.73 13.0 3.84 13.3 3.95
45
10.6 3.19 11.1 3.37 11.5 3.47 11.7 3.54 12.0 3.61 12.3 3.72 12.7 3.83
48
10.0 3.03 10.6 3.20 10.9 3.30 11.1 3.37 11.4 3.43 11.7 3.54 12.0 3.64
50
9.5 2.79 10.1 2.94 10.4 3.04 10.6 3.10 10.8 3.16 11.1 3.25 11.4 3.35
52
9.1 2.56 9.6 2.71 9.9 2.79 10.1 2.85 10.3 2.91 10.6 2.99 10.9 3.08
55
8.6 2.36 9.1 2.49 9.4 2.57 9.6 2.62 9.7 2.67 10.0
2.75 10.3 2.83
