Chigo CHV Mini Series - Page 39

CHV Mini VRF 50/60Hz
38 201908
CHV Mini Series Service Manual
Combination
(%)
(Capacity
index)
Outdoor Air
temperature
(
°
C DB)
Indoor temperature (
°
C WB)
DB: 20.8, WB: 14 DB: 23.3, WB: 16 DB: 25.8, WB: 18 DB: 27, WB: 19 DB: 28.2, WB: 20 DB: 30.7, WB: 22 DB: 32, WB: 24
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
110%
-5 9.5 1.43 10.0 1.51 10.3 1.55 10.6 1.58 10.8 1.62 11.1 1.66 11.4 1.71
-2 9.3 1.44 9.8 1.52 10.1 1.57 10.3 1.60 10.6 1.63 10.9 1.68 11.2 1.73
0 9.1 1.46 9.6 1.54 9.9 1.58 10.1 1.62 10.3 1.65 10.7 1.70 11.0 1.75
2 9.0 1.47 9.4 1.55 9.7 1.60 9.9 1.63 10.1 1.67 10.4 1.71 10.7 1.76
4 8.8 1.48 9.3 1.57 9.6 1.62 9.8 1.65 9.9 1.68 10.2 1.73 10.5 1.78
6 8.6 1.50 9.1 1.58 9.4 1.63 9.6 1.67 9.8 1.70 10.0 1.75 10.3 1.80
8 8.4 1.51 8.9 1.60
9.2 1.65 9.4 1.68 9.6 1.72 9.8 1.77 10.1 1.82
10 11.3 2.01 11.9 2.12 12.3 2.19 12.5 2.23 12.8 2.28 13.2 2.35 13.6 2.41
12
11.1 2.09 11.7 2.21 12.1 2.28 12.3 2.33 12.5 2.37 12.9 2.44 13.3 2.51
14
10.9 2.18 11.5 2.30 11.8 2.38 12.1 2.42 12.3 2.47 12.7 2.54 13.0 2.62
16
10.6 2.27 11.2 2.40 11.6 2.47 11.8 2.52 12.1 2.57 12.4 2.65 12.8 2.73
18
12.4 2.55 13.0 2.69 13.5 2.77 13.7 2.83 14.0 2.89 14.4 2.97 14.8 3.06
20
12.1 2.57 12.8 2.71 13.2 2.80 13.5 2.86 13.7 2.91 14.1 3.00 14.5 3.09
21
11.9 2.60 12.5 2.74 12.9 2.83 13.2 2.89 13.5 2.94 13.9 3.03 14.3 3.12
23
11.6 2.62 12.3 2.77 12.7 2.86 12.9 2.92 13.2 2.97 13.6 3.06 14.0 3.15
25
11.4 2.65 12.1
2.80 12.4 2.89 12.7 2.95 12.9 3.00 13.3 3.09 13.7 3.18
27
14.0 3.31 14.8 3.49 15.3 3.60 15.6 3.67 15.9 3.75 16.4 3.86 16.9 3.97
29
13.8 3.34 14.5 3.53 15.0 3.64 15.3 3.71 15.6 3.79 16.1 3.90 16.5 4.01
31
13.5 3.37 14.3 3.56 14.7 3.67 15.0 3.75 15.3 3.82 15.8 3.94 16.2 4.05
33
13.2 3.41 14.0 3.60 14.4 3.71 14.7 3.79 15.0 3.86 15.4 3.98 15.9 4.09
35
13.0 3.44 13.7 3.63 14.1 3.75 14.4 3.83 14.7 3.90 15.1 4.02 15.6 4.13
37
12.7 3.46 13.4 3.65 13.8 3.77 14.1 3.84 14.4 3.92 14.8 4.04 15.3 4.15
39
12.1 3.39 12.8 3.58 13.2 3.69 13.4 3.77 13.7 3.84 14.1 3.96 14.5 4.07
41
11.5 3.32 12.1 3.51 12.5 3.62 12.8 3.69 13.0 3.77 13.4 3.88 13.8 3.99
43
10.9 3.26
11.5 3.44 11.9 3.55 12.1 3.62 12.4 3.69 12.7 3.80 13.1 3.91
45
10.4 3.16 10.9 3.33 11.3 3.44 11.5 3.51 11.7 3.58 12.1 3.68 12.4 3.79
48
9.8 3.00 10.4 3.17 10.7 3.27 10.9 3.33 11.2 3.40 11.5 3.50 11.8 3.60
50
9.3 2.76 9.9 2.91 10.2 3.01 10.4 3.07 10.6 3.13 10.9 3.22 11.2 3.31
52
8.9 2.54 9.4 2.68 9.7 2.77 9.9 2.82 10.1 2.88 10.4 2.96 10.7 3.05
55
8.4 2.34 8.9 2.47 9.2 2.54 9.4 2.60 9.6 2.65 9.8 2.73 10.1 2.80
100%
-5 9.2 1.40 9.7 1.48 10.0 1.52 10.2 1.55 10.5 1.58 10.8 1.63 11.1 1.68
-2 9.0 1.41 9.5 1.49 9.8 1.54 10.0 1.57 10.2 1.60 10.5 1.65 10.9 1.69
0 8.9 1.43 9.4 1.51 9.7 1.55 9.9 1.58 10.0 1.62 10.3 1.66 10.6 1.71
2 8.7 1.44 9.2 1.52 9.5 1.57 9.7 1.60 9.9 1.63 10.1 1.68 10.4 1.73
4 8.5 1.46 9.0 1.54 9.3 1.58 9.5 1.62 9.7 1.65 9.9 1.70 10.2 1.75
6 8.4 1.47 8.8 1.55 9.1 1.60 9.3 1.63 9.5 1.67 9.7 1.72 10.0 1.76
8 8.2 1.49 8.6 1.57 8.9 1.62 9.1 1.65 9.3 1.68 9.6 1.73 9.8 1.78
10 11.0 1.97 11.6 2.08 11.9 2.15 12.2 2.19 12.4 2.23 12.8 2.30 13.2 2.36
12
10.7 2.05 11.3 2.17 11.7 2.24 11.9 2.28 12.2 2.33 12.5 2.40 12.9 2.46
14
10.5 2.14 11.1 2.26 11.5 2.33 11.7 2.38 11.9 2.42 12.3 2.49 12.6 2.57
16
10.3 2.23 10.9 2.35 11.3 2.43 11.5 2.48 11.7 2.52 12.1 2.60 12.4 2.67
18
12.0 2.50 12.7 2.64 13.1 2.72 13.3 2.77 13.6 2.83 14.0 2.91 14.4
3.00
20
11.8 2.52 12.4 2.66 12.8 2.75 13.1 2.80 13.3 2.86 13.7 2.94 14.1 3.03
21
11.5 2.55 12.2 2.69 12.6 2.77 12.8 2.83 13.1 2.89 13.5 2.97 13.8 3.06
23
11.3 2.57 11.9 2.72 12.3 2.80 12.6 2.86 12.8 2.92 13.2 3.00 13.6 3.09
25
11.1 2.60 11.7 2.74 12.1 2.83 12.3 2.89 12.6 2.95 12.9 3.03 13.3 3.12
27
13.6 3.24 14.4 3.42 14.9 3.53 15.2 3.60 15.5 3.67 15.9 3.78 16.4 3.89
29
13.4 3.27 14.1 3.46 14.6 3.57 14.9 3.64 15.2 3.71 15.6 3.82 16.0 3.93
31
13.1 3.31 13.8 3.49 14.3 3.60 14.6 3.68 14.9 3.75 15.3 3.86 15.7 3.97
33
12.9 3.34 13.6 3.53 14.0 3.64 14.3 3.71 14.6 3.79 15.0 3.90 15.4 4.01
35
12.6 3.38 13.3 3.56 13.7 3.68 14.0 3.75 14.3 3.83 14.7 3.94
15.1 4.05
37
12.3 3.39 13.0 3.58 13.4 3.69 13.7 3.81 14.0 3.84 14.4 3.96 14.8 4.07
39
11.7 3.32 12.4 3.51 12.8 3.62 13.4 3.87 13.3 3.77 13.7 3.88 14.1 3.99
41
11.1 3.26 11.8 3.44 12.1 3.55 13.2 3.93 12.6 3.69 13.0 3.80 13.4 3.91
43
10.6 3.19 11.2 3.37 11.5 3.48 12.9 4.00 12.0 3.62 12.4 3.72 12.7 3.83
45
10.1 3.10 10.6 3.27 11.0 3.37 12.7 4.06 11.4 3.51 11.7 3.61 12.1 3.72
48
9.6 2.94 10.1 3.11 10.4 3.20 12.4 4.12 10.8 3.33 11.1 3.43 11.5 3.53
50
9.1 2.71 9.6 2.86 9.9 2.95 12.2 4.19 10.3 3.07 10.6 3.16 10.9 3.25
52
8.6 2.49 9.1 2.63 9.4 2.71 11.9 4.26 9.8 2.82 10.1 2.90 10.3 2.99
55
8.2 2.29 8.6 2.42 8.9 2.49 11.7 4.33 9.3 2.60 9.6
2.67 9.8 2.75
