CHV Mini VRF 50/60Hz
201908 39
Part 2 - Outdoor Units
Combination
(%)
(Capacity
index)
Outdoor Air
temperature
(
°
C DB)
Indoor temperature (
°
C WB)
DB: 20.8, WB: 14 DB: 23.3, WB: 16 DB: 25.8, WB: 18 DB: 27, WB: 19 DB: 28.2, WB: 20 DB: 30.7, WB: 22 DB: 32, WB: 24
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
90%
-5 8.8 1.31 9.2 1.39 9.5 1.43 9.7 1.46 9.9 1.49 10.2 1.53 10.5 1.58
-2 8.6 1.33 9.1 1.40 9.4 1.45 9.5 1.47 9.7 1.50 10.0 1.55 10.3 1.59
0 8.4 1.34 8.9 1.42 9.2 1.46 9.4 1.49 9.5 1.52 9.8 1.56 10.1 1.61
2 8.3 1.35 8.7 1.43 9.0 1.47 9.2 1.50 9.4 1.54 9.6 1.58 9.9 1.63
4 8.1 1.37 8.5 1.44 8.8 1.49 9.0 1.52 9.2 1.55 9.4 1.60 9.7 1.64
6 7.9 1.38 8.4 1.46 8.6 1.50 8.8 1.54 9.0 1.57 9.3 1.61 9.5 1.66
8 7.8 1.40 8.2 1.47
8.5 1.52 8.6 1.55 8.8 1.58 9.1 1.63 9.3 1.68
10 10.4 1.85 11.0 1.96 11.3 2.02 11.6 2.06 11.8 2.10 12.2 2.16 12.5 2.22
12
10.2 1.93 10.8 2.04 11.1 2.10 11.3 2.14 11.6 2.19 11.9 2.25 12.3 2.32
14
10.0 2.01 10.6 2.12 10.9 2.19 11.1 2.23 11.3 2.28 11.7 2.35 12.0 2.41
16
9.8 2.09 10.4 2.21 10.7 2.28 10.9 2.33 11.1 2.37 11.5 2.44 11.8 2.51
18
11.4 2.35 12.0 2.48 12.4 2.56 12.7 2.61 12.9 2.66 13.3 2.74 13.7 2.82
20
11.2 2.37 11.8 2.50 12.2 2.58 12.4 2.63 12.7 2.69 13.0 2.77 13.4 2.84
21
11.0 2.39 11.6 2.53 11.9 2.61 12.2 2.66 12.4 2.71 12.8 2.79 13.2 2.87
23
10.7 2.42 11.3 2.55 11.7 2.63 11.9 2.69 12.2 2.74 12.5 2.82 12.9 2.90
25
10.5 2.44 11.1
2.58 11.5 2.66 11.7 2.71 11.9 2.77 12.3 2.85 12.6 2.93
27
13.0 3.05 13.7 3.22 14.1 3.32 14.4 3.39 14.7 3.45 15.1 3.56 15.5 3.66
29
12.7 3.08 13.4 3.25 13.8 3.35 14.1 3.42 14.4 3.49 14.8 3.59 15.2 3.69
31
12.5 3.11 13.1 3.28 13.6 3.39 13.8 3.45 14.1 3.52 14.5 3.63 14.9 3.73
33
12.2 3.14 12.9 3.32 13.3 3.42 13.6 3.49 13.8 3.56 14.2 3.66 14.7 3.77
35
12.0 3.17 12.6 3.35 13.0 3.45 13.3 3.53 13.6 3.60 14.0 3.70 14.4 3.81
37
11.7 3.19 12.4 3.37 12.8 3.47 13.0 3.54 13.3 3.61 13.7 3.72 14.1 3.83
39
11.1 3.12 11.8 3.30 12.1 3.40 12.4 3.47 12.6 3.54 13.0 3.65 13.4 3.75
41
10.6 3.06 11.2 3.23 11.5 3.33 11.8 3.40 12.0 3.47 12.4 3.57 12.7 3.67
43
10.1 3.00
10.6 3.17 11.0 3.27 11.2 3.33 11.4 3.40 11.7 3.50 12.1 3.60
45
9.6 2.91 10.1 3.07 10.4 3.17 10.6 3.23 10.8 3.30 11.1 3.40 11.5 3.49
48
9.1 2.77 9.6 2.92 9.9 3.01 10.1 3.07 10.3 3.13 10.6 3.23 10.9 3.32
50
8.6 2.54 9.1 2.69 9.4 2.77 9.6 2.83 9.8 2.88 10.1 2.97 10.3 3.05
52
8.2 2.34 8.6 2.47 8.9 2.55 9.1 2.60 9.3 2.65 9.6 2.73 9.8 2.81
55
7.8 2.15 8.2 2.27 8.5 2.34 8.6 2.39 8.8 2.44 9.1 2.51 9.3 2.58
80%
-5 7.9 1.19 8.4 1.25 8.6 1.29 8.8 1.32 9.0 1.35 9.3 1.39 9.5 1.43
-2 7.8 1.20 8.2 1.27 8.5 1.31 8.6 1.33 8.8 1.36 9.1 1.40 9.3 1.44
0 7.6 1.21 8.0 1.28 8.3 1.32 8.5 1.35 8.6 1.37 8.9 1.41 9.1 1.46
2 7.5 1.22 7.9 1.29 8.1 1.33 8.3 1.36 8.5 1.39 8.7 1.43 9.0 1.47
4 7.3 1.24 7.7 1.31 8.0 1.35 8.1 1.37 8.3 1.40 8.5 1.44 8.8 1.48
6 7.2 1.25 7.6 1.32 7.8 1.36 8.0 1.39 8.1 1.42 8.4 1.46 8.6 1.50
8 7.0 1.26 7.4 1.33 7.7 1.37 7.8 1.40 8.0 1.43 8.2 1.47 8.5 1.51
10 9.4 1.68 10.0 1.77 10.3 1.82 10.5 1.86 10.7 1.90 11.0 1.95 11.3 2.01
12
9.2 1.74 9.8 1.84 10.1 1.90 10.3 1.94 10.5 1.98 10.8 2.04 11.1 2.09
14
9.1 1.82 9.6 1.92 9.9 1.98 10.1 2.02 10.3 2.06 10.6 2.12 10.9 2.18
16
8.9 1.89 9.4 2.00 9.7 2.06 9.9 2.10 10.1 2.15 10.4 2.21 10.7 2.27
18
10.3 2.12 10.9 2.24 11.2 2.31 11.5 2.36 11.7 2.40 12.0 2.48 12.4
2.55
20
10.1 2.14 10.7 2.26 11.0 2.33 11.2 2.38 11.5 2.43 11.8 2.50 12.1 2.57
21
9.9 2.16 10.5 2.29 10.8 2.36 11.0 2.41 11.2 2.45 11.6 2.53 11.9 2.60
23
9.7 2.19 10.3 2.31 10.6 2.38 10.8 2.43 11.0 2.48 11.3 2.55 11.7 2.62
25
9.5 2.21 10.1 2.33 10.4 2.41 10.6 2.45 10.8 2.50 11.1 2.58 11.4 2.65
27
11.7 2.76 12.4 2.91 12.8 3.00 13.0 3.06 13.3 3.12 13.7 3.21 14.1 3.31
29
11.5 2.78 12.1 2.94 12.5 3.03 12.8 3.09 13.0 3.15 13.4 3.25 13.8 3.34
31
11.3 2.81 11.9 2.97 12.3 3.06 12.5 3.12 12.8 3.19 13.2 3.28 13.5 3.37
33
11.1 2.84 11.7 3.00 12.0 3.09 12.3 3.16 12.5 3.22 12.9 3.31 13.3 3.41
35
10.8 2.87 11.4 3.03 11.8 3.12 12.0 3.19 12.3 3.25 12.6 3.35
13.0 3.44
37
10.6 2.88 11.2 3.04 11.6 3.14 11.8 3.20 12.0 3.27 12.4 3.36 12.7 3.46
39
10.1 2.83 10.6 2.98 11.0 3.08 11.2 3.14 11.4 3.20 11.8 3.30 12.1 3.39
41
9.6 2.77 10.1 2.92 10.4 3.02 10.6 3.08 10.9 3.14 11.2 3.23 11.5 3.32
43
9.1 2.71 9.6 2.86 9.9 2.95 10.1 3.02 10.3 3.08 10.6 3.17 10.9 3.26
45
8.6 2.63 9.1 2.78 9.4 2.87 9.6 2.92 9.8 2.98 10.1 3.07 10.4 3.16
48
8.2 2.50 8.7 2.64 8.9 2.72 9.1 2.78 9.3 2.83 9.6 2.92 9.9 3.00
50
7.8 2.30 8.2 2.43 8.5 2.50 8.7 2.56 8.8 2.61 9.1 2.68 9.4 2.76
52
7.4 2.12 7.8 2.23 8.1 2.30 8.2 2.35 8.4 2.40 8.7 2.47 8.9 2.54
55
7.0 1.95 7.4 2.06 7.7 2.12 7.8 2.16 8.0 2.21 8.2
2.27 8.5 2.34
