Combination
(%)
(Capacity
index)
Outdoor Air
temperature
(
°
C DB)
Indoor temperature (
°
C WB)
DB: 20.8, WB: 14 DB: 23.3, WB: 16 DB: 25.8, WB: 18 DB: 27, WB: 19 DB: 28.2, WB: 20 DB: 30.7, WB: 22 DB: 32, WB: 24
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
70%
-5 7.1 1.06 7.5 1.12 7.7 1.16 7.9 1.18 8.0 1.20 8.3 1.24 8.5 1.28
-2 7.0 1.07 7.3 1.13 7.6 1.17 7.7 1.19 7.9 1.22 8.1 1.25 8.4 1.29
0 6.8 1.08 7.2 1.14 7.4 1.18 7.6 1.20 7.7 1.23 8.0 1.26 8.2 1.30
2 6.7 1.10 7.1 1.16 7.3 1.19 7.4 1.22 7.6 1.24 7.8 1.28 8.0 1.31
4 6.6 1.11 6.9 1.17 7.1 1.20 7.3 1.23 7.4 1.25 7.7 1.29 7.9 1.33
6 6.4 1.12 6.8 1.18 7.0 1.22 7.1 1.24 7.3 1.27 7.5 1.30 7.7 1.34
8 6.3 1.13 6.7 1.19
6.9 1.23 7.0 1.25 7.1 1.28 7.4 1.32 7.6 1.35
10 8.4 1.50 8.9 1.58 9.2 1.63 9.4 1.66 9.6 1.70 9.8 1.75 10.1 1.80
12
8.3 1.56 8.7 1.65 9.0 1.70 9.2 1.73 9.4 1.77 9.7 1.82 9.9 1.87
14
8.1 1.63 8.6 1.72 8.8 1.77 9.0 1.81 9.2 1.84 9.5 1.90 9.7 1.95
16
8.0 1.69 8.4 1.79 8.7 1.84 8.8 1.88 9.0 1.92 9.3 1.98 9.5 2.03
18
9.2 1.90 9.8 2.00 10.1 2.07 10.3 2.11 10.5 2.15 10.8 2.21 11.1 2.28
20
9.1 1.92 9.6 2.02 9.9 2.09 10.1 2.13 10.3 2.17 10.6 2.24 10.9 2.30
21
8.9 1.94 9.4 2.04 9.7 2.11 9.9 2.15 10.1 2.19 10.4 2.26 10.7 2.32
23
8.7 1.96 9.2 2.06 9.5 2.13 9.7 2.17 9.9 2.22 10.2 2.28 10.5 2.35
25
8.5 1.98 9.0
2.08 9.3 2.15 9.5 2.19 9.7 2.24 10.0 2.30 10.2 2.37
27
10.5 2.46 11.1 2.60 11.4 2.68 11.7 2.74 11.9 2.79 12.3 2.87 12.6 2.96
29
10.3 2.49 10.9 2.63 11.2 2.71 11.4 2.77 11.7 2.82 12.0 2.90 12.4 2.99
31
10.1 2.51 10.7 2.65 11.0 2.74 11.2 2.79 11.4 2.85 11.8 2.93 12.1 3.02
33
9.9 2.54 10.4 2.68 10.8 2.77 11.0 2.82 11.2 2.88 11.5 2.96 11.9 3.05
35
9.7 2.57 10.2 2.71 10.6 2.79 10.8 2.85 11.0 2.91 11.3 2.99 11.6 3.08
37
9.5 2.58 10.0 2.72 10.4 2.81 10.6 2.86 10.8 2.92 11.1 3.01 11.4 3.09
39
9.3 2.59 9.8 2.73 10.1 2.82 10.4 2.88 10.6 2.94 10.9 3.02 11.2 3.11
41
9.1 2.60 9.6 2.75 9.9 2.84 10.1 2.89 10.3 2.95 10.7 3.04 11.0 3.12
43
8.9 2.62
9.4 2.76 9.7 2.85 9.9 2.91 10.1 2.97 10.4 3.05 10.7 3.14
45
8.8 2.63 9.3 2.78 9.5 2.86 9.7 2.92 9.9 2.98 10.2 3.07 10.5 3.16
48
8.6 2.64 9.1 2.79 9.4 2.88 9.5 2.94 9.7 3.00 10.0 3.08 10.3 3.17
50
8.4 2.66 8.9 2.80 9.2 2.89 9.4 2.95 9.5 3.01 9.8 3.10 10.1 3.19
52
8.3 2.67 8.7 2.82 9.0 2.91 9.2 2.97 9.4 3.03 9.6 3.11 9.9 3.20
55
8.1 2.68 8.5 2.83 8.8 2.92 9.0 2.98 9.2 3.04 9.4 3.13 9.7 3.22
60%
-5 6.3 0.94 6.6 0.99 6.8 1.02 7.0 1.04 7.1 1.06 7.3 1.09 7.5 1.12
-2 6.1 0.95 6.5 1.00 6.7 1.03 6.8 1.05 7.0 1.07 7.2 1.10 7.4 1.14
0 6.0 0.96 6.4 1.01 6.6 1.04 6.7 1.06 6.8 1.08 7.0 1.12 7.2 1.15
2 5.9 0.97 6.2 1.02 6.4 1.05 6.6 1.07 6.7 1.09 6.9 1.13 7.1 1.16
4 5.8 0.98 6.1 1.03 6.3 1.06 6.4 1.08 6.6 1.11 6.8 1.14 7.0 1.17
6 5.7 0.99 6.0 1.04 6.2 1.07 6.3 1.09 6.4 1.12 6.6 1.15 6.8 1.18
8 5.6 0.99 5.9 1.05 6.1 1.08 6.2 1.11 6.3 1.13 6.5 1.16 6.7 1.19
10 7.5 1.32 7.9 1.39 8.1 1.44 8.3 1.47 8.4 1.50 8.7 1.54 8.9 1.58
12
7.3 1.38 7.7 1.45 8.0 1.50 8.1 1.53 8.3 1.56 8.5 1.60 8.8 1.65
14
7.2 1.43 7.6 1.51 7.8 1.56 8.0 1.59 8.1 1.62 8.4 1.67 8.6 1.72
16
7.0 1.49 7.4 1.58 7.7 1.63 7.8 1.66 8.0 1.69 8.2 1.74 8.4 1.79
18
8.2 1.67 8.6 1.77 8.9 1.82 9.1 1.86 9.2 1.90 9.5 1.95 9.8
2.01
20
8.0 1.69 8.4 1.78 8.7 1.84 8.9 1.88 9.1 1.91 9.3 1.97 9.6 2.03
21
7.8 1.71 8.3 1.80 8.5 1.86 8.7 1.90 8.9 1.93 9.2 1.99 9.4 2.05
23
7.7 1.72 8.1 1.82 8.4 1.88 8.5 1.92 8.7 1.95 9.0 2.01 9.2 2.07
25
7.5 1.74 8.0 1.84 8.2 1.90 8.4 1.93 8.5 1.97 8.8 2.03 9.0 2.09
27
9.3 2.17 9.8 2.29 10.1 2.37 10.3 2.41 10.5 2.46 10.8 2.53 11.1 2.61
29
9.1 2.19 9.6 2.32 9.9 2.39 10.1 2.44 10.3 2.49 10.6 2.56 10.9 2.63
31
8.9 2.22 9.4 2.34 9.7 2.41 9.9 2.46 10.1 2.51 10.4 2.59 10.7 2.66
33
8.7 2.24 9.2 2.36 9.5 2.44 9.7 2.49 9.9 2.54 10.2 2.61 10.5 2.69
35
8.6 2.26 9.0 2.39 9.3 2.46 9.5 2.51 9.7 2.56 10.0 2.64
10.3 2.71
37
8.4 2.27 8.9 2.40 9.1 2.47 9.3 2.53 9.5 2.58 9.8 2.65 10.1 2.73
39
8.2 2.28 8.7 2.41 9.0 2.49 9.1 2.54 9.3 2.59 9.6 2.66 9.9 2.74
41
8.1 2.30 8.5 2.42 8.8 2.50 9.0 2.55 9.1 2.60 9.4 2.68 9.7 2.75
43
7.9 2.31 8.3 2.43 8.6 2.51 8.8 2.56 9.0 2.61 9.2 2.69 9.5 2.77
45
7.7 2.32 8.2 2.45 8.4 2.52 8.6 2.58 8.8 2.63 9.0 2.70 9.3 2.78
48
7.6 2.33 8.0 2.46 8.3 2.54 8.4 2.59 8.6 2.64 8.9 2.72 9.1 2.80
50
7.4 2.34 7.9 2.47 8.1 2.55 8.3 2.60 8.4 2.65 8.7 2.73 8.9 2.81
52
7.3 2.35 7.7 2.48 7.9 2.56 8.1 2.61 8.3 2.67 8.5 2.75 8.7 2.82
55
7.1 2.37 7.5 2.50 7.8 2.58 7.9 2.63 8.1 2.68 8.3
2.76 8.6 2.84
