CHV Mini VRF 50/60Hz
201908 41
Part 2 - Outdoor Units
Combination
(%)
(Capacity
index)
Outdoor Air
temperature
(
°
C DB)
Indoor temperature (
°
C WB)
DB: 20.8, WB: 14 DB: 23.3, WB: 16 DB: 25.8, WB: 18 DB: 27, WB: 19 DB: 28.2, WB: 20 DB: 30.7, WB: 22 DB: 32, WB: 24
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
50%
-5 5.4 0.81 5.7 0.86 5.9 0.88 6.0 0.90 6.2 0.92 6.3 0.95 6.5 0.97
-2 5.3 0.82 5.6 0.86 5.8 0.89 5.9 0.91 6.0 0.93 6.2 0.96 6.4 0.98
0 5.2 0.83 5.5 0.87 5.7 0.90 5.8 0.92 5.9 0.94 6.1 0.97 6.3 0.99
2 5.1 0.84 5.4 0.88 5.6 0.91 5.7 0.93 5.8 0.95 6.0 0.98 6.2 1.00
4 5.0 0.84 5.3 0.89 5.5 0.92 5.6 0.94 5.7 0.96 5.9 0.98 6.0 1.01
6 4.9 0.85 5.2 0.90 5.4 0.93 5.5 0.95 5.6 0.97 5.8 0.99 5.9 1.02
8 4.8 0.86 5.1 0.91
5.3 0.94 5.4 0.96 5.5 0.98 5.6 1.00 5.8 1.03
10 6.5 1.14 6.8 1.21 7.0 1.24 7.2 1.27 7.3 1.30 7.5 1.33 7.8 1.37
12
6.3 1.19 6.7 1.26 6.9 1.30 7.0 1.32 7.2 1.35 7.4 1.39 7.6 1.43
14
6.2 1.24 6.6 1.31 6.8 1.35 6.9 1.38 7.0 1.41 7.3 1.45 7.5 1.49
16
6.1 1.29 6.4 1.36 6.6 1.41 6.8 1.44 6.9 1.46 7.1 1.51 7.3 1.55
18
7.1 1.45 7.5 1.53 7.7 1.58 7.9 1.61 8.0 1.64 8.3 1.69 8.5 1.74
20
6.9 1.46 7.3 1.54 7.6 1.59 7.7 1.63 7.9 1.66 8.1 1.71 8.3 1.76
21
6.8 1.48 7.2 1.56 7.4 1.61 7.6 1.64 7.7 1.67 7.9 1.72 8.2 1.77
23
6.7 1.49 7.0 1.58 7.3 1.62 7.4 1.66 7.6 1.69 7.8 1.74 8.0 1.79
25
6.5 1.51 6.9
1.59 7.1 1.64 7.3 1.67 7.4 1.71 7.6 1.76 7.9 1.81
27
8.0 1.88 8.5 1.98 8.8 2.05 8.9 2.09 9.1 2.13 9.4 2.19 9.7 2.26
29
7.9 1.90 8.3 2.00 8.6 2.07 8.8 2.11 8.9 2.15 9.2 2.22 9.5 2.28
31
7.7 1.92 8.2 2.03 8.4 2.09 8.6 2.13 8.8 2.17 9.0 2.24 9.3 2.30
33
7.6 1.94 8.0 2.05 8.3 2.11 8.4 2.15 8.6 2.20 8.8 2.26 9.1 2.33
35
7.4 1.96 7.8 2.07 8.1 2.13 8.3 2.18 8.4 2.22 8.7 2.28 8.9 2.35
37
7.3 1.97 7.7 2.08 7.9 2.14 8.1 2.19 8.3 2.23 8.5 2.30 8.7 2.36
39
7.1 1.98 7.5 2.09 7.8 2.15 7.9 2.20 8.1 2.24 8.3 2.31 8.6 2.37
41
7.0 1.99 7.4 2.10 7.6 2.16 7.8 2.21 7.9 2.25 8.2 2.32 8.4 2.38
43
6.9 2.00
7.2 2.11 7.5 2.17 7.6 2.22 7.8 2.26 8.0 2.33 8.2 2.40
45
6.7 2.01 7.1 2.12 7.3 2.19 7.5 2.23 7.6 2.27 7.8 2.34 8.1 2.41
48
6.6 2.02 7.0 2.13 7.2 2.20 7.3 2.24 7.5 2.29 7.7 2.35 7.9 2.42
50
6.5 2.03 6.8 2.14 7.0 2.21 7.2 2.25 7.3 2.30 7.5 2.36 7.7 2.43
52
6.3 2.04 6.7 2.15 6.9 2.22 7.0 2.26 7.2 2.31 7.4 2.38 7.6 2.44
55
6.2 2.05 6.5 2.16 6.7 2.23 6.9 2.27 7.0 2.32 7.2 2.39 7.4 2.46
