CHV Mini VRF 50/60Hz
42 201908
CHV Mini Series Service Manual
CHV-DH160W/R1
TC: Total Capacity (kW); PI: Power Input (kW) (Compressor + Outdoor fan motor)
Combination
(%)
(Capacity
index)
Outdoor Air
temperature
(
°
C DB)
Indoor temperature (
°
C WB)
DB: 20.8, WB: 14 DB: 23.3, WB: 16 DB: 25.8, WB: 18 DB: 27, WB: 19 DB: 28.2, WB: 20 DB: 30.7, WB: 22 DB: 32, WB: 24
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
130%
-5 11.3 1.84 11.9 1.94 12.3 2.01 12.5 2.05 12.8 2.09 13.2 2.15 13.5 2.21
-2 11.1 1.86 11.7 1.96 12.0 2.03 12.3 2.07 12.5 2.11 12.9 2.17 13.3 2.23
0 10.8 1.88 11.4 1.98 11.8 2.05 12.0 2.09 12.3 2.13 12.6 2.19 13.0 2.25
2 10.6 1.90 11.2 2.00 11.6 2.07 11.8 2.11 12.0 2.15 12.4 2.21 12.8 2.28
4 10.4 1.92 11.0 2.02 11.3 2.09 11.6 2.13 11.8 2.17 12.2 2.24 12.5 2.30
6 10.2 1.94 10.8 2.04 11.1 2.11 11.4 2.15 11.6 2.19 11.9 2.26 12.3 2.32
8 10.0 1.96 10.6 2.06
10.9 2.13 11.1 2.17 11.4 2.22 11.7 2.28 12.0 2.35
10 13.4 2.60 14.2 2.74 14.6 2.83 14.9 2.88 15.2 2.94 15.6 3.03 16.1 3.12
12
13.1 2.70 13.9 2.85 14.3 2.94 14.6 3.00 14.9 3.06 15.3 3.16 15.8 3.25
14
12.9 2.82 13.6 2.97 14.0 3.07 14.3 3.13 14.6 3.19 15.0 3.29 15.5 3.38
16
12.6 2.93 13.3 3.10 13.8 3.20 14.0 3.26 14.3 3.33 14.7 3.42 15.2 3.52
18
14.7 3.29 15.5 3.47 16.0 3.58 16.3 3.65 16.6 3.73 17.1 3.84 17.6 3.95
20
14.4 3.32 15.2 3.51 15.7 3.62 16.0 3.69 16.3 3.76 16.8 3.88 17.3 3.99
21
14.1 3.36 14.9 3.54 15.4 3.65 15.7 3.73 16.0 3.80 16.5 3.91 16.9 4.03
23
13.8 3.39 14.6 3.58 15.1 3.69 15.4 3.77 15.7 3.84 16.1 3.95 16.6 4.07
25
13.6 3.42 14.3
3.61 14.8 3.73 15.1 3.80 15.4 3.88 15.8 3.99 16.3 4.11
27
16.7 4.27 17.6 4.51 18.2 4.65 18.5 4.75 18.9 4.84 19.5 4.98 20.0 5.12
29
16.4 4.31 17.3 4.55 17.8 4.70 18.2 4.79 18.5 4.89 19.1 5.03 19.6 5.18
31
16.0 4.36 16.9 4.60 17.5 4.74 17.8 4.84 18.2 4.94 18.7 5.08 19.2 5.23
33
15.7 4.40 16.6 4.65 17.1 4.79 17.5 4.89 17.8 4.99 18.3 5.14 18.9 5.28
35
15.4 4.45 16.3 4.69 16.8 4.84 17.1 4.94 17.5 5.04 18.0 5.19 18.5 5.34
37
15.1 4.47 15.9 4.72 16.4 4.87 16.8 4.96 17.1 5.06 17.6 5.21 18.1 5.36
39
14.3 4.38 15.1 4.62 15.6 4.77 15.9 4.87 16.3 4.96 16.7 5.11 17.2 5.25
41
13.6 4.29 14.4 4.53 14.8 4.67 15.1 4.77 15.4 4.86 15.9 5.01 16.4 5.15
43
12.9 4.21
13.7 4.44 14.1 4.58 14.4 4.67 14.7 4.77 15.1 4.91 15.5 5.05
45
12.3 4.08 13.0 4.31 13.4 4.44 13.7 4.53 13.9 4.62 14.3 4.76 14.8 4.90
48
11.7 3.88 12.3 4.09 12.7 4.22 13.0 4.31 13.2 4.39 13.6 4.52 14.0 4.65
50
11.1 3.57 11.7 3.76 12.1 3.88 12.3 3.96 12.6 4.04 12.9 4.16 13.3 4.28
52
10.5 3.28 11.1 3.46 11.5 3.57 11.7 3.64 12.0 3.72 12.3 3.83 12.7 3.94
55
10.0 3.02 10.6 3.19 10.9 3.29 11.1 3.35 11.4 3.42 11.7 3.52 12.0 3.62
120%
-5 11.1 1.82 11.7 1.93 12.1 1.99 12.3 2.03 12.5 2.07 12.9 2.13 13.3 2.19
-2 10.9 1.84 11.5 1.94 11.8 2.01 12.1 2.05 12.3 2.09 12.7 2.15 13.0 2.21
0 10.6 1.86 11.2 1.96 11.6 2.03 11.8 2.07 12.1 2.11 12.4 2.17 12.8 2.23
2 10.4 1.88 11.0 1.98 11.4 2.05 11.6 2.09 11.8 2.13 12.2 2.19 12.5 2.26
4 10.2 1.90 10.8 2.00 11.1 2.07 11.4 2.11 11.6 2.15 11.9 2.22 12.3 2.28
6 10.0 1.92 10.6 2.02 10.9 2.09 11.1 2.13 11.4 2.17 11.7 2.24 12.0 2.30
8 9.8 1.94 10.4 2.05 10.7 2.11 10.9 2.15 11.1 2.20 11.5 2.26 11.8 2.32
10 13.2 2.57 13.9 2.71 14.3 2.80 14.6 2.86 14.9 2.91 15.4 3.00 15.8 3.09
12
12.9 2.68 13.6 2.83 14.0 2.92 14.3 2.98 14.6 3.04 15.0 3.12 15.5 3.21
14
12.6 2.79 13.3 2.94 13.8 3.04 14.1 3.10 14.3 3.16 14.8 3.25 15.2 3.35
16
12.4 2.91 13.1 3.07 13.5 3.16 13.8 3.23 14.1 3.29 14.5 3.39 14.9 3.49
18
14.4 3.26 15.2 3.44 15.7 3.55 16.0 3.62 16.3 3.69 16.8 3.80 17.3
3.91
20
14.1 3.29 14.9 3.47 15.4 3.58 15.7 3.66 16.0 3.73 16.5 3.84 16.9 3.95
21
13.8 3.32 14.6 3.51 15.1 3.62 15.4 3.69 15.7 3.77 16.2 3.88 16.6 3.99
23
13.6 3.36 14.3 3.54 14.8 3.65 15.1 3.73 15.4 3.80 15.8 3.92 16.3 4.03
25
13.3 3.39 14.0 3.58 14.5 3.69 14.8 3.77 15.1 3.84 15.5 3.96 16.0 4.07
27
16.4 4.23 17.3 4.46 17.8 4.61 18.2 4.70 18.5 4.79 19.1 4.93 19.6 5.08
29
16.0 4.27 16.9 4.51 17.5 4.65 17.8 4.75 18.2 4.84 18.7 4.98 19.3 5.13
31
15.7 4.32 16.6 4.56 17.1 4.70 17.5 4.80 17.8 4.89 18.4 5.03 18.9 5.18
33
15.4 4.36 16.3 4.60 16.8 4.75 17.1 4.84 17.5 4.94 18.0 5.09 18.5 5.23
35
15.1 4.40 16.0 4.65 16.5 4.79 16.8 4.89 17.1 4.99 17.6 5.14
18.1 5.28
37
14.8 4.43 15.6 4.67 16.1 4.82 16.5 4.92 16.8 5.02 17.3 5.16 17.8 5.31
39
14.1 4.34 14.9 4.58 15.3 4.72 15.6 4.82 16.0 4.91 16.4 5.06 16.9 5.20
41
13.4 4.25 14.1 4.49 14.6 4.63 14.9 4.72 15.2 4.82 15.6 4.96 16.0 5.10
43
12.7 4.17 13.4 4.40 13.8 4.54 14.1 4.63 14.4 4.72 14.8 4.86 15.2 5.00
45
12.1 4.04 12.7 4.26 13.1 4.40 13.4 4.49 13.7 4.58 14.1 4.71 14.5 4.85
48
11.5 3.84 12.1 4.05 12.5 4.18 12.7 4.26 13.0 4.35 13.4 4.48 13.8 4.61
50
10.9 3.53 11.5 3.73 11.9 3.84 12.1 3.92 12.3 4.00 12.7 4.12 13.1 4.24
52
10.3 3.25 10.9 3.43 11.3 3.54 11.5 3.61 11.7 3.68 12.1 3.79 12.4 3.90
55
9.8 2.99 10.4 3.15 10.7 3.25 10.9 3.32 11.1 3.39 11.5
3.49 11.8 3.59
