CHV Mini VRF 50/60Hz
201908 43
Part 2 - Outdoor Units
Combination
(%)
(Capacity
index)
Outdoor Air
temperature
(
°
C DB)
Indoor temperature (
°
C WB)
DB: 20.8, WB: 14 DB: 23.3, WB: 16 DB: 25.8, WB: 18 DB: 27, WB: 19 DB: 28.2, WB: 20 DB: 30.7, WB: 22 DB: 32, WB: 24
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
110%
-5 10.9 1.81 11.5 1.91 11.8 1.97 12.1 2.01 12.3 2.05 12.7 2.11 13.0 2.17
-2 10.6 1.82 11.2 1.93 11.6 1.99 11.8 2.03 12.1 2.07 12.4 2.13 12.8 2.19
0 10.4 1.84 11.0 1.95 11.4 2.01 11.6 2.05 11.8 2.09 12.2 2.15 12.5 2.21
2 10.2 1.86 10.8 1.97 11.1 2.03 11.4 2.07 11.6 2.11 11.9 2.17 12.3 2.23
4 10.0 1.88 10.6 1.98 10.9 2.05 11.1 2.09 11.4 2.13 11.7 2.19 12.0 2.26
6 9.8 1.90 10.4 2.00 10.7 2.07 10.9 2.11 11.1 2.15 11.5 2.22 11.8 2.28
8 9.6 1.92 10.2 2.03
10.5 2.09 10.7 2.13 10.9 2.17 11.2 2.24 11.6 2.30
10 12.9 2.55 13.6 2.69 14.1 2.77 14.3 2.83 14.6 2.89 15.1 2.97 15.5 3.06
12
12.7 2.65 13.4 2.80 13.8 2.89 14.1 2.95 14.3 3.01 14.8 3.09 15.2 3.18
14
12.4 2.76 13.1 2.92 13.5 3.01 13.8 3.07 14.1 3.13 14.5 3.22 14.9 3.32
16
12.2 2.88 12.8 3.04 13.2 3.13 13.5 3.20 13.8 3.26 14.2 3.36 14.6 3.45
18
14.1 3.23 14.9 3.40 15.4 3.51 15.7 3.58 16.0 3.66 16.5 3.76 17.0 3.87
20
13.9 3.26 14.6 3.44 15.1 3.55 15.4 3.62 15.7 3.69 16.2 3.80 16.6 3.91
21
13.6 3.29 14.3 3.47 14.8 3.58 15.1 3.66 15.4 3.73 15.8 3.84 16.3 3.95
23
13.3 3.32 14.1 3.51 14.5 3.62 14.8 3.69 15.1 3.77 15.5 3.88 16.0 3.99
25
13.1 3.36 13.8
3.54 14.2 3.66 14.5 3.73 14.8 3.81 15.2 3.92 15.7 4.03
27
16.1 4.19 16.9 4.42 17.5 4.56 17.8 4.65 18.2 4.75 18.7 4.89 19.3 5.03
29
15.7 4.23 16.6 4.47 17.1 4.61 17.5 4.70 17.8 4.80 18.4 4.94 18.9 5.08
31
15.4 4.27 16.3 4.51 16.8 4.65 17.1 4.75 17.5 4.84 18.0 4.99 18.5 5.13
33
15.1 4.32 16.0 4.56 16.5 4.70 16.8 4.80 17.1 4.89 17.7 5.04 18.2 5.18
35
14.8 4.36 15.7 4.60 16.2 4.75 16.5 4.85 16.8 4.94 17.3 5.09 17.8 5.23
37
14.5 4.38 15.3 4.63 15.8 4.77 16.2 4.87 16.5 4.97 17.0 5.11 17.4 5.26
39
13.8 4.29 14.6 4.53 15.0 4.68 15.3 4.77 15.6 4.87 16.1 5.01 16.6 5.15
41
13.1 4.21 13.8 4.44 14.3 4.58 14.6 4.68 14.9 4.77 15.3 4.91 15.7 5.05
43
12.5 4.12
13.2 4.35 13.6 4.49 13.8 4.58 14.1 4.67 14.5 4.81 15.0 4.95
45
11.8 4.00 12.5 4.22 12.9 4.36 13.2 4.45 13.4 4.53 13.8 4.67 14.2 4.80
48
11.2 3.80 11.9 4.01 12.2 4.14 12.5 4.22 12.7 4.31 13.1 4.43 13.5 4.56
50
10.7 3.50 11.3 3.69 11.6 3.81 11.9 3.89 12.1 3.96 12.5 4.08 12.8 4.20
52
10.2 3.22 10.7 3.40 11.1 3.50 11.3 3.57 11.5 3.65 11.8 3.75 12.2 3.86
55
9.6 2.96 10.2 3.12 10.5 3.22 10.7 3.29 10.9 3.35 11.3 3.45 11.6 3.55
100%
-5 10.5 1.77 11.1 1.87 11.5 1.93 11.7 1.97 11.9 2.01 12.3 2.07 12.6 2.13
-2 10.3 1.79 10.9 1.89 11.3 1.95 11.5 1.99 11.7 2.03 12.1 2.09 12.4 2.15
0 10.1 1.81 10.7 1.91 11.0 1.97 11.3 2.01 11.5 2.05 11.8 2.11 12.2 2.17
2 9.9 1.83 10.5 1.93 10.8 1.99 11.0 2.03 11.3 2.07 11.6 2.13 11.9 2.19
4 9.7 1.84 10.3 1.95 10.6 2.01 10.8 2.05 11.0 2.09 11.4 2.15 11.7 2.21
6 9.5 1.86 10.1 1.97 10.4 2.03 10.6 2.07 10.8 2.11 11.1 2.17 11.5 2.23
8 9.4 1.88 9.9 1.99 10.2 2.05 10.4 2.09 10.6 2.13 10.9 2.19 11.2 2.26
10 12.5 2.50 13.2 2.63 13.6 2.72 13.9 2.77 14.2 2.83 14.6 2.91 15.0 3.00
12
12.3 2.60 13.0 2.74 13.4 2.83 13.7 2.89 13.9 2.95 14.3 3.03 14.7 3.12
14
12.0 2.71 12.7 2.86 13.1 2.95 13.4 3.01 13.7 3.07 14.1 3.16 14.5 3.25
16
11.8 2.82 12.5 2.98 12.9 3.07 13.1 3.14 13.4 3.20 13.8 3.29 14.2 3.39
18
13.7 3.16 14.5 3.34 14.9 3.44 15.2 3.51 15.5 3.58 16.0 3.69 16.5
3.79
20
13.4 3.19 14.2 3.37 14.6 3.48 14.9 3.55 15.2 3.62 15.7 3.73 16.1 3.83
21
13.2 3.23 13.9 3.41 14.4 3.51 14.6 3.58 14.9 3.66 15.4 3.76 15.8 3.87
23
12.9 3.26 13.6 3.44 14.1 3.55 14.4 3.62 14.6 3.69 15.1 3.80 15.5 3.91
25
12.7 3.29 13.4 3.47 13.8 3.58 14.1 3.66 14.4 3.73 14.8 3.84 15.2 3.95
27
15.6 4.11 16.5 4.33 17.0 4.47 17.3 4.56 17.7 4.65 18.2 4.79 18.7 4.93
29
15.3 4.15 16.1 4.38 16.6 4.52 17.0 4.61 17.3 4.70 17.8 4.84 18.3 4.98
31
15.0 4.19 15.8 4.42 16.3 4.56 16.6 4.66 17.0 4.75 17.5 4.89 18.0 5.03
33
14.7 4.23 15.5 4.47 16.0 4.61 16.3 4.70 16.6 4.80 17.1 4.94 17.6 5.08
35
14.4 4.28 15.2 4.51 15.7 4.66 16.0 4.75 16.3 4.85 16.8 4.99
17.3 5.13
37
14.1 4.30 14.9 4.54 15.4 4.68 15.7 4.83 16.0 4.87 16.5 5.01 16.9 5.16
39
13.4 4.21 14.2 4.44 14.6 4.58 15.4 4.90 15.2 4.77 15.6 4.91 16.1 5.05
41
12.7 4.13 13.4 4.36 13.9 4.49 15.1 4.98 14.4 4.68 14.9 4.81 15.3 4.95
43
12.1 4.04 12.8 4.27 13.2 4.40 14.8 5.06 13.7 4.58 14.1 4.72 14.5 4.85
45
11.5 3.92 12.1 4.14 12.5 4.27 14.5 5.14 13.0 4.45 13.4 4.58 13.8 4.71
48
10.9 3.73 11.5 3.93 11.9 4.06 14.2 5.22 12.4 4.22 12.7 4.35 13.1 4.47
50
10.4 3.43 10.9 3.62 11.3 3.73 13.9 5.31 11.8 3.89 12.1 4.00 12.4 4.11
52
9.9 3.15 10.4 3.33 10.7 3.43 13.6 5.39 11.2 3.57 11.5 3.68 11.8 3.78
55
9.4 2.90 9.9 3.06 10.2 3.16 13.3 5.48 10.6 3.29 10.9
3.39 11.2 3.48
