CHV Mini VRF 50/60Hz
44 201908
CHV Mini Series Service Manual
Combination
(%)
(Capacity
index)
Outdoor Air
temperature
(
°
C DB)
Indoor temperature (
°
C WB)
DB: 20.8, WB: 14 DB: 23.3, WB: 16 DB: 25.8, WB: 18 DB: 27, WB: 19 DB: 28.2, WB: 20 DB: 30.7, WB: 22 DB: 32, WB: 24
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
90%
-5 10.0 1.66 10.6 1.76 10.9 1.81 11.1 1.85 11.3 1.89 11.7 1.94 12.0 2.00
-2 9.8 1.68 10.4 1.77 10.7 1.83 10.9 1.87 11.1 1.91 11.5 1.96 11.8 2.02
0 9.6 1.70 10.2 1.79 10.5 1.85 10.7 1.89 10.9 1.92 11.2 1.98 11.5 2.04
2 9.4 1.72 10.0 1.81 10.3 1.87 10.5 1.91 10.7 1.94 11.0 2.00 11.3 2.06
4 9.3 1.73 9.8 1.83 10.1 1.89 10.3 1.93 10.5 1.96 10.8 2.02 11.1 2.08
6 9.1 1.75 9.6 1.85 9.9 1.91 10.1 1.94 10.3 1.98 10.6 2.04 10.9 2.10
8 8.9 1.77 9.4 1.87
9.7 1.93 9.9 1.96 10.1 2.00 10.4 2.06 10.7 2.12
10 11.9 2.35 12.6 2.48 13.0 2.56 13.2 2.61 13.5 2.66 13.9 2.74 14.3 2.82
12
11.7 2.44 12.3 2.58 12.7 2.66 13.0 2.72 13.2 2.77 13.6 2.85 14.0 2.93
14
11.4 2.55 12.1 2.69 12.5 2.77 12.7 2.83 13.0 2.89 13.3 2.97 13.7 3.06
16
11.2 2.65 11.8 2.80 12.2 2.89 12.5 2.95 12.7 3.01 13.1 3.09 13.5 3.18
18
13.0 2.97 13.8 3.14 14.2 3.24 14.5 3.30 14.8 3.37 15.2 3.47 15.6 3.57
20
12.8 3.00 13.5 3.17 13.9 3.27 14.2 3.34 14.5 3.40 14.9 3.50 15.3 3.60
21
12.5 3.03 13.2 3.20 13.6 3.30 13.9 3.37 14.2 3.44 14.6 3.54 15.0 3.64
23
12.3 3.06 13.0 3.23 13.4 3.34 13.6 3.40 13.9 3.47 14.3 3.57 14.7 3.68
25
12.0 3.09 12.7
3.27 13.1 3.37 13.4 3.44 13.6 3.51 14.0 3.61 14.4 3.71
27
14.8 3.86 15.6 4.07 16.1 4.20 16.5 4.29 16.8 4.37 17.3 4.50 17.8 4.63
29
14.5 3.90 15.3 4.12 15.8 4.25 16.1 4.33 16.5 4.42 16.9 4.55 17.4 4.68
31
14.2 3.94 15.0 4.16 15.5 4.29 15.8 4.38 16.1 4.46 16.6 4.59 17.1 4.73
33
14.0 3.98 14.7 4.20 15.2 4.33 15.5 4.42 15.8 4.51 16.3 4.64 16.7 4.77
35
13.7 4.02 14.4 4.24 14.9 4.38 15.2 4.47 15.5 4.55 16.0 4.69 16.4 4.82
37
13.4 4.04 14.2 4.26 14.6 4.40 14.9 4.49 15.2 4.58 15.6 4.71 16.1 4.85
39
12.7 3.96 13.4 4.18 13.9 4.31 14.2 4.40 14.4 4.49 14.9 4.62 15.3 4.75
41
12.1 3.88 12.8 4.09 13.2 4.22 13.4 4.31 13.7 4.40 14.1 4.53 14.5 4.65
43
11.5 3.80
12.1 4.01 12.5 4.14 12.8 4.22 13.0 4.31 13.4 4.43 13.8 4.56
45
10.9 3.69 11.5 3.89 11.9 4.01 12.1 4.10 12.4 4.18 12.7 4.30 13.1 4.42
48
10.4 3.50 10.9 3.70 11.3 3.81 11.5 3.89 11.8 3.97 12.1 4.09 12.4 4.20
50
9.9 3.22 10.4 3.40 10.7 3.51 10.9 3.58 11.2 3.65 11.5 3.76 11.8 3.87
52
9.4 2.96 9.9 3.13 10.2 3.23 10.4 3.29 10.6 3.36 10.9 3.46 11.2 3.56
55
8.9 2.73 9.4 2.88 9.7 2.97 9.9 3.03 10.1 3.09 10.4 3.18 10.7 3.27
80%
-5 9.1 1.51 9.6 1.59 9.9 1.64 10.1 1.67 10.3 1.71 10.6 1.76 10.9 1.81
-2 8.9 1.52 9.4 1.60 9.7 1.66 9.9 1.69 10.1 1.72 10.4 1.77 10.7 1.82
0 8.7 1.54 9.2 1.62 9.5 1.67 9.7 1.71 9.9 1.74 10.2 1.79 10.5 1.84
2 8.5 1.55 9.0 1.64 9.3 1.69 9.5 1.72 9.7 1.76 10.0 1.81 10.3 1.86
4 8.4 1.57 8.8 1.65 9.1 1.71 9.3 1.74 9.5 1.78 9.8 1.83 10.0 1.88
6 8.2 1.58 8.7 1.67 8.9 1.72 9.1 1.76 9.3 1.79 9.6 1.85 9.9 1.90
8 8.0 1.60 8.5 1.69 8.8 1.74 8.9 1.78 9.1 1.81 9.4 1.87 9.7 1.92
10 10.8 2.12 11.4 2.24 11.7 2.31 12.0 2.36 12.2 2.40 12.6 2.48 12.9 2.55
12
10.6 2.21 11.2 2.33 11.5 2.41 11.7 2.46 12.0 2.50 12.3 2.58 12.7 2.65
14
10.4 2.30 10.9 2.43 11.3 2.51 11.5 2.56 11.7 2.61 12.1 2.69 12.4 2.76
16
10.2 2.40 10.7 2.53 11.1 2.61 11.3 2.66 11.5 2.72 11.8 2.80 12.2 2.88
18
11.8 2.69 12.5 2.84 12.8 2.93 13.1 2.99 13.4 3.05 13.8 3.14 14.2
3.23
20
11.6 2.71 12.2 2.87 12.6 2.96 12.8 3.02 13.1 3.08 13.5 3.17 13.9 3.26
21
11.3 2.74 12.0 2.89 12.3 2.99 12.6 3.05 12.8 3.11 13.2 3.20 13.6 3.29
23
11.1 2.77 11.7 2.92 12.1 3.02 12.4 3.08 12.6 3.14 13.0 3.23 13.3 3.32
25
10.9 2.80 11.5 2.95 11.9 3.05 12.1 3.11 12.4 3.17 12.7 3.26 13.1 3.36
27
13.4 3.49 14.1 3.68 14.6 3.80 14.9 3.88 15.2 3.96 15.6 4.07 16.1 4.19
29
13.1 3.53 13.9 3.72 14.3 3.84 14.6 3.92 14.9 4.00 15.3 4.11 15.8 4.23
31
12.9 3.56 13.6 3.76 14.0 3.88 14.3 3.96 14.6 4.04 15.0 4.16 15.5 4.27
33
12.6 3.60 13.3 3.80 13.8 3.92 14.0 4.00 14.3 4.08 14.7 4.20 15.2 4.32
35
12.4 3.63 13.1 3.84 13.5 3.96 13.8 4.04 14.0 4.12 14.4 4.24
14.9 4.36
37
12.1 3.65 12.8 3.85 13.2 3.98 13.5 4.06 13.8 4.14 14.2 4.26 14.6 4.38
39
11.5 3.58 12.2 3.78 12.6 3.90 12.8 3.98 13.1 4.06 13.5 4.18 13.8 4.29
41
11.0 3.51 11.6 3.70 11.9 3.82 12.2 3.90 12.4 3.97 12.8 4.09 13.1 4.21
43
10.4 3.44 11.0 3.63 11.3 3.74 11.6 3.82 11.8 3.90 12.1 4.01 12.5 4.12
45
9.9 3.33 10.4 3.52 10.8 3.63 11.0 3.70 11.2 3.78 11.5 3.89 11.9 4.00
48
9.4 3.17 9.9 3.34 10.2 3.45 10.4 3.52 10.6 3.59 11.0 3.70 11.3 3.80
50
8.9 2.91 9.4 3.08 9.7 3.17 9.9 3.24 10.1 3.30 10.4 3.40 10.7 3.50
52
8.5 2.68 8.9 2.83 9.2 2.92 9.4 2.98 9.6 3.04 9.9 3.13 10.2 3.22
55
8.1 2.47 8.5 2.60 8.8 2.69 8.9 2.74 9.1 2.80 9.4
2.88 9.7 2.96
