CHV Mini VRF 50/60Hz
201908 45
Part 2 - Outdoor Units
Combination
(%)
(Capacity
index)
Outdoor Air
temperature
(
°
C DB)
Indoor temperature (
°
C WB)
DB: 20.8, WB: 14 DB: 23.3, WB: 16 DB: 25.8, WB: 18 DB: 27, WB: 19 DB: 28.2, WB: 20 DB: 30.7, WB: 22 DB: 32, WB: 24
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
70%
-5 8.1 1.35 8.6 1.42 8.8 1.47 9.0 1.50 9.2 1.53 9.5 1.57 9.7 1.62
-2 8.0 1.36 8.4 1.44 8.7 1.48 8.8 1.51 9.0 1.54 9.3 1.59 9.5 1.63
0 7.8 1.37 8.2 1.45 8.5 1.50 8.7 1.53 8.8 1.56 9.1 1.60 9.4 1.65
2 7.6 1.39 8.1 1.46 8.3 1.51 8.5 1.54 8.7 1.57 8.9 1.62 9.2 1.66
4 7.5 1.40 7.9 1.48 8.2 1.53 8.3 1.56 8.5 1.59 8.7 1.63 9.0 1.68
6 7.4 1.42 7.8 1.49 8.0 1.54 8.2 1.57 8.3 1.60 8.6 1.65 8.8 1.70
8 7.2 1.43 7.6 1.51
7.8 1.56 8.0 1.59 8.2 1.62 8.4 1.67 8.6 1.72
10 9.6 1.90 10.2 2.00 10.5 2.07 10.7 2.11 10.9 2.15 11.3 2.21 11.6 2.28
12
9.5 1.98 10.0 2.09 10.3 2.15 10.5 2.20 10.7 2.24 11.0 2.31 11.4 2.37
14
9.3 2.06 9.8 2.17 10.1 2.24 10.3 2.29 10.5 2.33 10.8 2.40 11.1 2.47
16
9.1 2.14 9.6 2.26 9.9 2.33 10.1 2.38 10.3 2.43 10.6 2.50 10.9 2.57
18
10.6 2.40 11.1 2.54 11.5 2.62 11.7 2.67 12.0 2.72 12.3 2.80 12.7 2.88
20
10.4 2.43 10.9 2.56 11.3 2.64 11.5 2.70 11.7 2.75 12.1 2.83 12.4 2.91
21
10.2 2.45 10.7 2.59 11.1 2.67 11.3 2.72 11.5 2.78 11.8 2.86 12.2 2.94
23
10.0 2.48 10.5 2.61 10.8 2.70 11.1 2.75 11.3 2.81 11.6 2.89 11.9 2.97
25
9.8 2.50 10.3
2.64 10.6 2.72 10.8 2.78 11.1 2.84 11.4 2.92 11.7 3.00
27
12.0 3.12 12.7 3.29 13.1 3.40 13.3 3.47 13.6 3.54 14.0 3.64 14.4 3.75
29
11.8 3.15 12.4 3.33 12.8 3.43 13.1 3.50 13.3 3.57 13.7 3.68 14.1 3.78
31
11.5 3.18 12.2 3.36 12.6 3.47 12.8 3.54 13.1 3.61 13.5 3.72 13.8 3.82
33
11.3 3.22 11.9 3.40 12.3 3.50 12.6 3.57 12.8 3.65 13.2 3.75 13.6 3.86
35
11.1 3.25 11.7 3.43 12.1 3.54 12.3 3.61 12.6 3.68 12.9 3.79 13.3 3.90
37
10.9 3.27 11.5 3.45 11.8 3.56 12.1 3.63 12.3 3.70 12.7 3.81 13.0 3.92
39
10.6 3.28 11.2 3.46 11.6 3.57 11.8 3.65 12.1 3.72 12.4 3.83 12.8 3.94
41
10.4 3.30 11.0 3.48 11.4 3.59 11.6 3.66 11.8 3.74 12.2 3.85 12.5 3.96
43
10.2 3.31
10.8 3.50 11.1 3.61 11.4 3.68 11.6 3.76 11.9 3.87 12.3 3.98
45
10.0 3.33 10.6 3.52 10.9 3.63 11.1 3.70 11.4 3.78 11.7 3.89 12.0 4.00
48
9.8 3.35 10.4 3.53 10.7 3.65 10.9 3.72 11.1 3.79 11.5 3.91 11.8 4.02
50
9.6 3.36 10.2 3.55 10.5 3.66 10.7 3.74 10.9 3.81 11.2 3.93 11.6 4.04
52
9.4 3.38 10.0 3.57 10.3 3.68 10.5 3.76 10.7 3.83 11.0 3.94 11.3 4.06
55
9.2 3.40 9.8 3.59 10.1 3.70 10.3 3.78 10.5 3.85 10.8 3.96 11.1 4.08
60%
-5 7.2 1.19 7.6 1.25 7.8 1.29 8.0 1.32 8.1 1.34 8.4 1.38 8.6 1.42
-2 7.0 1.20 7.4 1.27 7.7 1.31 7.8 1.33 8.0 1.36 8.2 1.40 8.4 1.44
0 6.9 1.21 7.3 1.28 7.5 1.32 7.7 1.35 7.8 1.37 8.0 1.41 8.3 1.45
2 6.8 1.22 7.1 1.29 7.4 1.33 7.5 1.36 7.7 1.39 7.9 1.43 8.1 1.47
4 6.6 1.24 7.0 1.30 7.2 1.34 7.4 1.37 7.5 1.40 7.7 1.44 7.9 1.48
6 6.5 1.25 6.9 1.32 7.1 1.36 7.2 1.39 7.4 1.41 7.6 1.46 7.8 1.50
8 6.4 1.26 6.7 1.33 6.9 1.37 7.1 1.40 7.2 1.43 7.4 1.47 7.6 1.51
10 8.5 1.67 9.0 1.77 9.3 1.82 9.5 1.86 9.7 1.90 9.9 1.95 10.2 2.01
12
8.4 1.74 8.8 1.84 9.1 1.90 9.3 1.94 9.5 1.97 9.7 2.03 10.0 2.09
14
8.2 1.81 8.6 1.92 8.9 1.98 9.1 2.02 9.3 2.06 9.6 2.12 9.8 2.18
16
8.0 1.89 8.5 2.00 8.7 2.06 8.9 2.10 9.1 2.14 9.4 2.21 9.6 2.27
18
9.3 2.12 9.8 2.24 10.2 2.31 10.4 2.35 10.6 2.40 10.9 2.47 11.2
2.54
20
9.1 2.14 9.7 2.26 10.0 2.33 10.2 2.38 10.4 2.43 10.7 2.50 11.0 2.57
21
9.0 2.16 9.5 2.28 9.8 2.35 10.0 2.40 10.2 2.45 10.5 2.52 10.8 2.59
23
8.8 2.18 9.3 2.30 9.6 2.38 9.8 2.43 10.0 2.47 10.3 2.55 10.5 2.62
25
8.6 2.21 9.1 2.33 9.4 2.40 9.6 2.45 9.8 2.50 10.1 2.57 10.3 2.65
27
10.6 2.75 11.2 2.90 11.5 3.00 11.8 3.06 12.0 3.12 12.4 3.21 12.7 3.30
29
10.4 2.78 11.0 2.93 11.3 3.03 11.5 3.09 11.8 3.15 12.1 3.24 12.5 3.34
31
10.2 2.81 10.8 2.96 11.1 3.06 11.3 3.12 11.5 3.18 11.9 3.28 12.2 3.37
33
10.0 2.84 10.5 2.99 10.9 3.09 11.1 3.15 11.3 3.21 11.7 3.31 12.0 3.40
35
9.8 2.86 10.3 3.02 10.7 3.12 10.9 3.18 11.1 3.25 11.4 3.34
11.8 3.44
37
9.6 2.88 10.1 3.04 10.4 3.13 10.7 3.20 10.9 3.26 11.2 3.36 11.5 3.45
39
9.4 2.89 9.9 3.05 10.2 3.15 10.4 3.21 10.7 3.28 11.0 3.38 11.3 3.47
41
9.2 2.91 9.7 3.07 10.0 3.17 10.2 3.23 10.4 3.30 10.8 3.39 11.1 3.49
43
9.0 2.92 9.5 3.08 9.8 3.18 10.0 3.25 10.2 3.31 10.5 3.41 10.8 3.51
45
8.9 2.94 9.3 3.10 9.6 3.20 9.8 3.26 10.0 3.33 10.3 3.43 10.6 3.52
48
8.7 2.95 9.2 3.12 9.4 3.21 9.6 3.28 9.8 3.34 10.1 3.44 10.4 3.54
50
8.5 2.97 9.0 3.13 9.3 3.23 9.4 3.30 9.6 3.36 9.9 3.46 10.2 3.56
52
8.3 2.98 8.8 3.15 9.1 3.25 9.3 3.31 9.4 3.38 9.7 3.48 10.0 3.58
55
8.2 3.00 8.6 3.16 8.9 3.26 9.1 3.33 9.3 3.40 9.5
3.50 9.8 3.59
