CHV Mini VRF 50/60Hz
46 201908
CHV Mini Series Service Manual
Note:
1. is tested under our standard condition.
2. In cooling mode, avoid running the unit when the outdoor air temperature is above 46 degrees.
3. The above table shows the average value of conditions may operate.
Combination
(%)
(Capacity
index)
Outdoor Air
temperature
(
°
C DB)
Indoor temperature (
°
C WB)
DB: 20.8, WB: 14 DB: 23.3, WB: 16 DB: 25.8, WB: 18 DB: 27, WB: 19 DB: 28.2, WB: 20 DB: 30.7, WB: 22 DB: 32, WB: 24
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
50%
-5 6.2 1.03 6.6 1.08 6.8 1.12 6.9 1.14 7.0 1.16 7.3 1.20 7.5 1.23
-2 6.1 1.04 6.4 1.10 6.6 1.13 6.8 1.15 6.9 1.18 7.1 1.21 7.3 1.25
0 6.0 1.05 6.3 1.11 6.5 1.14 6.6 1.16 6.8 1.19 7.0 1.22 7.2 1.26
2 5.9 1.06 6.2 1.12 6.4 1.15 6.5 1.18 6.6 1.20 6.8 1.24 7.0 1.27
4 5.7 1.07 6.1 1.13 6.3 1.16 6.4 1.19 6.5 1.21 6.7 1.25 6.9 1.28
6 5.6 1.08 5.9 1.14 6.1 1.18 6.3 1.20 6.4 1.22 6.6 1.26 6.8 1.30
8 5.5 1.09 5.8 1.15
6.0 1.19 6.1 1.21 6.3 1.24 6.4 1.27 6.6 1.31
10 7.4 1.45 7.8 1.53 8.1 1.58 8.2 1.61 8.4 1.64 8.6 1.69 8.9 1.74
12
7.2 1.51 7.7 1.59 7.9 1.64 8.1 1.68 8.2 1.71 8.5 1.76 8.7 1.81
14
7.1 1.57 7.5 1.66 7.7 1.71 7.9 1.75 8.1 1.78 8.3 1.83 8.5 1.89
16
7.0 1.64 7.4 1.73 7.6 1.78 7.7 1.82 7.9 1.85 8.1 1.91 8.4 1.96
18
8.1 1.83 8.5 1.94 8.8 2.00 9.0 2.04 9.2 2.08 9.4 2.14 9.7 2.20
20
7.9 1.85 8.4 1.96 8.6 2.02 8.8 2.06 9.0 2.10 9.3 2.16 9.5 2.22
21
7.8 1.87 8.2 1.98 8.5 2.04 8.6 2.08 8.8 2.12 9.1 2.18 9.3 2.25
23
7.6 1.89 8.0 2.00 8.3 2.06 8.5 2.10 8.6 2.14 8.9 2.21 9.2 2.27
25
7.5 1.91 7.9
2.02 8.1 2.08 8.3 2.12 8.5 2.16 8.7 2.23 9.0 2.29
27
9.2 2.38 9.7 2.51 10.0 2.59 10.2 2.65 10.4 2.70 10.7 2.78 11.0 2.86
29
9.0 2.41 9.5 2.54 9.8 2.62 10.0 2.67 10.2 2.73 10.5 2.81 10.8 2.89
31
8.8 2.43 9.3 2.57 9.6 2.65 9.8 2.70 10.0 2.75 10.3 2.84 10.6 2.92
33
8.7 2.45 9.1 2.59 9.4 2.67 9.6 2.73 9.8 2.78 10.1 2.86 10.4 2.95
35
8.5 2.48 9.0 2.62 9.3 2.70 9.4 2.76 9.6 2.81 9.9 2.89 10.2 2.98
37
8.3 2.49 8.8 2.63 9.1 2.71 9.3 2.77 9.4 2.82 9.7 2.91 10.0 2.99
39
8.2 2.50 8.6 2.64 8.9 2.73 9.1 2.78 9.2 2.84 9.5 2.92 9.8 3.01
41
8.0 2.52 8.4 2.66 8.7 2.74 8.9 2.80 9.1 2.85 9.3 2.94 9.6 3.02
43
7.8 2.53
8.3 2.67 8.5 2.75 8.7 2.81 8.9 2.87 9.1 2.95 9.4 3.04
45
7.7 2.54 8.1 2.68 8.4 2.77 8.5 2.82 8.7 2.88 9.0 2.97 9.2 3.05
48
7.5 2.55 7.9 2.70 8.2 2.78 8.4 2.84 8.5 2.90 8.8 2.98 9.0 3.07
50
7.4 2.57 7.8 2.71 8.0 2.80 8.2 2.85 8.4 2.91 8.6 3.00 8.9 3.08
52
7.2 2.58 7.6 2.72 7.9 2.81 8.0 2.87 8.2 2.92 8.4 3.01 8.7 3.10
55
7.1 2.59 7.5 2.74 7.7 2.82 7.9 2.88 8.0 2.94 8.3 3.03 8.5 3.11
