CHV Mini VRF 50/60Hz
201908 47
Part 2 - Outdoor Units
CHV-DH080W/R1
TC: Total Capacity (kW); PI: Power Input (kW) (Compressor + Outdoor fan motor)
7.2 Heating
Combination (%)
(Capacity index)
Outdoor Air
temperature
(
°
C DB)
Indoor temperature(
°
C WB)
16 18 20 21 22 24
TC PI TC PI TC PI TC PI TC PI TC PI
°
C DB
°
C WB
kW kW kW kW kW kW kW kW kW kW kW kW
130%
-19.8 -20 6.0 1.6 6.0 1.7 6.0 1.8 6.0 1.9 5.9 2.0 5.9 2.0
-18.8 -19 6.1 1.6 6.1 1.8 6.1 1.9 6.0 1.9 6.0 2.0 6.0 2.1
-16.7 -17 6.3 1.7 6.3 1.8 6.3 2.0 6.3 2.0 6.3 2.0 6.2 2.1
-13.7 -15 6.6 1.8 6.6 1.9 6.5 2.0 6.5 2.0 6.5 2.1 6.5 2.2
-11.8 -13 6.9 1.9 6.9 2.0 6.8 2.1 6.8 2.1 6.8 2.2 6.8 2.3
-9.8 -11 7.2 2.0 7.2 2.0 7.1 2.1 7.1 2.2 7.1 2.3 7.1 2.4
-9.5 -10 7.4 2.0 7.3 2.1 7.3 2.2 7.3 2.2 7.3 2.3 7.3 2.4
-8.5 -9.1 7.5 2.0 7.5 2.1 7.5 2.2 7.5 2.3 7.5 2.3 7.4 2.4
-7 -7.6 7.8
2.1 7.8 2.2 7.7 2.3 7.7 2.3 7.7 2.4 7.7 2.4
-5 -5.6 8.2 2.2 8.2 2.3 8.1 2.4 8.1 2.4 8.1 2.4 8.1 2.5
-3 -3.7 8.6 2.3 8.5 2.3 8.5 2.4 8.5 2.4 8.5 2.5 8.5 2.6
0 -0.7 9.2 2.4 9.2 2.4 9.2 2.5 9.2 2.5 9.2 2.6 9.2 2.7
3 2.2 10.0 2.4 9.9 2.5 9.9 2.6 9.9 2.6 9.9 2.7 9.9 2.7
5 4.1 10.5 2.5 10.5 2.6 10.5 2.6 10.4 2.7 10.4 2.7 10.4 2.8
7 6 11.0 2.6 11.0 2.6 11.0 2.7 11.0 2.7 11.0 2.8 10.5 2.7
9 7.9 11.6 2.6 11.5 2.7 11.5 2.8 11.5 2.8 11.3 2.7 10.5 2.5
11 9.8 12.2 2.7 12.1 2.8 12.1 2.8 11.7 2.7 11.3 2.5 10.5 2.4
13 11.8 12.8 2.8 12.8 2.8 12.1 2.6 11.7
2.5 11.3 2.4 10.5 2.2
15 13.7 13.4 2.8 12.8 2.6 12.1 2.4 11.7 2.4 11.3 2.3 10.5 2.1
120%
-19.8 -20 6.0 1.8 6.0 1.9 5.9 2.0 5.9 2.0 5.9 2.1 5.9 2.2
-18.8 -19 6.1 1.8 6.0 1.9 6.0 2.0 6.0 2.0 6.0 2.1 6.0 2.2
-16.7 -17 6.3 1.9 6.3 2.0 6.2 2.0 6.2 2.1 6.2 2.2 6.2 2.3
-13.7 -15 6.6 2.0 6.5 2.0 6.5 2.1 6.5 2.2 6.5 2.2 6.5 2.3
-11.8 -13 6.8 2.0 6.8 2.1 6.8 2.2 6.8 2.2 6.8 2.3 6.8 2.4
-9.8 -11 7.2 2.1 7.1 2.2 7.1 2.3 7.1 2.3 7.1 2.4 7.1 2.4
-9.5 -10 7.3 2.1 7.3 2.2 7.3 2.3 7.3 2.4 7.3 2.4 7.3 2.4
-8.5 -9.1 7.5 2.2 7.5 2.2 7.5 2.3 7.4 2.4
7.4 2.4 7.4 2.5
-7 -7.6 7.7 2.2 7.7 2.3 7.7 2.4 7.7 2.4 7.7 2.4 7.7 2.5
-5 -5.6 8.2 2.3 8.1 2.4 8.1 2.4 8.1 2.5 8.1 2.5 8.1 2.6
-3 -3.7 8.5 2.4 8.5 2.4 8.5 2.5 8.5 2.5 8.5 2.6 8.5 2.6
0 -0.7 9.2 2.4 9.2 2.5 9.2 2.6 9.2 2.6 9.2 2.7 9.2 2.7
3 2.2 9.9 2.5 9.9 2.6 9.9 2.7 9.9 2.7 9.9 2.8 9.7 2.7
5 4.1 10.5 2.6 10.4 2.7 10.4 2.7 10.4 2.8 10.4 2.8 9.7 2.5
7 6 11.0 2.7 11.0 2.7 11.0 2.8 10.8 2.7 10.4 2.6 9.7 2.4
9 7.9 11.5 2.7 11.5 2.8 11.1 2.7 10.8 2.6 10.4 2.4 9.7 2.3
11 9.8 12.1 2.8 11.8 2.7 11.1 2.5 10.8 2.4 10.4 2.3 9.7 2.1
13
11.8 12.6 2.7 11.8 2.5 11.1 2.4 10.8 2.3 10.4 2.2 9.7 2.0
15 13.7 12.6 2.6 11.8 2.4 11.1 2.2 10.8 2.1 10.4 2.0 9.7 1.9
110%
-19.8 -20 6.0 1.9 5.9 2.0 5.9 2.1 5.9 2.2 5.9 2.2 5.9 2.3
-18.8 -19 6.0 2.0 6.0 2.0 6.0 2.1 6.0 2.2 6.0 2.2 6.0 2.3
-16.7 -17 6.3 2.0 6.2 2.1 6.3 2.2 6.2 2.2 6.2 2.3 6.2 2.4
-13.7 -15 6.5 2.1 6.5 2.2 6.5 2.3 6.5 2.3 6.5 2.4 6.5 2.4
-11.8 -13 6.8 2.1 6.8 2.2 6.8 2.3 6.8 2.4 6.8 2.4 6.8 2.5
-9.8 -11 7.1 2.2 7.1 2.3 7.1 2.4 7.1 2.4 7.1 2.4 7.1 2.5
-9.5 -10 7.3 2.3 7.3 2.3 7.3 2.4 7.3 2.4 7.3 2.5 7.2 2.6
-8.5 -9.1
7.5 2.3 7.4 2.4 7.4 2.4 7.4 2.5 7.4 2.5 7.4 2.3
-7 -7.6 7.7 2.3 7.7 2.4 7.7 2.5 7.7 2.5 7.7 2.5 7.7 2.6
-5 -5.6 8.1 2.4 8.1 2.5 8.1 2.5 8.1 2.6 8.1 2.6 8.0 2.7
-3 -3.7 8.5 2.4 8.5 2.5 8.5 2.6 8.5 2.6 8.5 2.7 8.5 2.7
0 -0.7 9.2 2.5 9.2 2.6 9.2 2.7 9.2 2.7 9.2 2.8 8.9 2.7
3 2.2 9.9 2.6 9.9 2.7 9.9 2.8 9.9 2.8 9.5 2.7 8.9 2.4
5 4.1 10.4 2.7 10.4 2.8 10.2 2.7 9.9 2.6 9.5 2.5 8.9 2.3
7 6 11.0 2.8 10.9 2.8 10.2 2.5 9.9 2.4 9.5 2.4 8.9 2.2
9 7.9 11.5 2.8 10.9 2.6 10.2 2.4 9.9 2.3 9.5 2.2 8.9 2.0
11 9.8 11.5 2.6 10.9 2.4 10.2
2.3 9.9 2.2 9.5 2.1 8.9 1.9
13 11.8 11.5 2.4 10.9 2.3 10.2 2.1 9.9 2.0 9.5 2.0 8.9 1.8
15 13.7 11.5 2.2 10.9 2.2 10.2 2.0 9.9 1.9 9.5 1.9 8.9 1.7
