CHV Mini VRF 50/60Hz
48 201908
CHV Mini Series Service Manual
Combination (%)
(Capacity index)
Outdoor Air
temperature
(
°
C DB)
Indoor temperature(
°
C WB)
16 18 20 21 22 24
TC PI TC PI TC PI TC PI TC PI TC PI
°
C DB
°
C WB
kW kW kW kW kW kW kW kW kW kW kW kW
100%
-19.8 -20 5.9 2.1 5.9 2.2 5.9 2.2 5.9 2.3 5.9 2.3 5.8 2.4
-18.8 -19 6.0 2.1 6.0 2.2 6.0 2.3 6.0 2.3 6.0 2.4 6.0 2.4
-16.7 -17 6.2 2.2 6.2 2.2 6.2 2.3 6.2 2.4 6.2 2.4 6.2 2.5
-13.7 -15 6.5 2.2 6.5 2.3 6.5 2.4 6.5 2.4 6.5 2.4 6.4 2.5
-11.8 -13 6.8 2.3 6.8 2.4 6.8 2.4 6.8 2.5 6.8 2.5 6.7 2.6
-9.8 -11 7.1 2.4 7.1 2.4 7.1 2.5 7.1 2.5 7.0 2.6 7.0 2.6
-9.5 -10 7.3 2.4 7.3 2.4 7.3 2.5 7.2 2.5 7.2 2.6 7.2 2.7
-8.5 -9.1 7.4 2.4 7.4 2.5 7.4 2.5 7.4 2.6 7.4 2.6 7.4 2.7
-7 -7.6 7.7
2.4 7.7 2.5 7.7 2.6 7.7 2.6 7.7 2.7 7.6 2.7
-5 -5.6 8.1 2.5 8.1 2.6 8.1 2.6 8.0 2.7 8.0 2.7 8.0 2.8
-3 -3.7 8.5 2.6 8.5 2.3 8.5 2.7 8.5 2.7 8.5 2.8 8.1 2.6
0 -0.7 9.2 2.7 9.2 2.7 9.0 2.8 9.0 2.7 8.7 2.6 8.1 2.4
3 2.2 9.9 2.7 9.9 2.8 9.0 2.6 9.0 2.5 8.7 2.4 8.1 2.2
5 4.1 10.4 2.8 9.9 2.6 9.0 2.4 9.0 2.3 8.7 2.2 8.1 2.0
7 6 10.5 2.6 9.9 2.4 9.0 2.3 9.0 2.2 8.7 2.1 8.1 2.0
9 7.9 10.5 2.5 9.9 2.3 9.0 2.1 9.0 2.0 8.7 2.0 8.1 1.8
11 9.8 10.5 2.3 9.9 2.2 9.0 2.0 9.0 2.0 8.7 1.9 8.1 1.7
13 11.8 10.5 2.2 9.9 2.0 9.0 1.9 9.0
1.8 8.7 1.8 8.1 1.6
15 13.7 10.5 2.0 9.9 1.9 9.0 1.8 9.0 1.7 8.7 1.6 8.1 1.6
90%
-19.8 -20 5.9 2.2 5.9 2.3 5.9 2.4 5.8 2.4 5.8 2.4 5.8 2.5
-18.8 -19 6.0 2.3 6.0 2.3 5.9 2.4 5.9 2.4 5.9 2.5 5.9 2.6
-16.7 -17 6.2 2.3 6.2 2.4 6.2 2.4 6.2 2.5 6.2 2.5 6.2 2.6
-13.7 -15 6.5 2.4 6.4 2.4 6.4 2.5 6.4 2.5 6.4 2.6 6.4 2.6
-11.8 -13 6.7 2.4 6.7 2.5 6.7 2.5 6.7 2.6 6.7 2.6 6.7 2.7
-9.8 -11 7.1 2.5 7.1 2.5 7.0 2.6 7.0 2.6 7.0 2.7 7.0 2.8
-9.5 -10 7.2 2.5 7.2 2.6 7.2 2.6 7.2 2.7 7.2 2.7 7.2 2.8
-8.5 -9.1 7.4 2.5 7.4 2.6 7.4 2.7 7.4 2.7
7.4 2.7 7.3 2.8
-7 -7.6 7.6 2.6 7.6 2.6 7.6 2.7 7.6 2.7 7.6 2.8 7.3 2.6
-5 -5.6 8.1 2.6 8.0 2.7 8.0 2.8 8.0 2.8 7.8 2.7 7.3 2.4
-3 -3.7 8.4 2.7 8.4 2.7 8.4 2.8 8.1 2.6 7.8 2.5 7.3 2.3
0 -0.7 9.1 2.8 8.9 2.7 8.4 2.5 8.1 2.4 7.8 2.3 7.3 2.1
3 2.2 9.4 2.6 8.9 2.4 8.4 2.3 8.1 2.2 7.8 2.1 7.3 1.9
5 4.1 9.4 2.4 8.9 2.3 8.4 2.1 8.1 2.0 7.8 2.0 7.3 1.8
7 6 9.4 2.3 8.9 2.2 8.4 2.0 8.1 2.0 7.8 1.9 7.3 1.7
9 7.9 9.4 2.2 8.9 2.0 8.4 1.9 8.1 1.8 7.8 1.8 7.3 1.6
11 9.8 9.4 2.0 8.9 1.9 8.4 1.8 8.1 1.7 7.8 1.6 7.3 1.6
13
11.8 9.4 2.0 8.9 1.8 8.4 1.7 8.1 1.6 7.8 1.6 7.3 1.5
15 13.7 9.4 1.8 8.9 1.7 8.4 1.6 8.1 1.6 7.8 1.5 7.3 1.4
80%
-19.8 -20 5.9 2.4 5.8 2.4 5.8 2.5 5.8 2.5 5.8 2.6 5.8 2.7
-18.8 -19 6.0 2.4 6.0 2.4 5.9 2.5 5.9 2.6 5.9 2.6 5.9 2.7
-16.7 -17 6.2 2.4 6.2 2.5 6.2 2.6 6.2 2.6 6.2 2.6 6.1 2.7
-13.7 -15 6.5 2.5 6.4 2.6 6.4 2.6 6.4 2.7 6.4 2.7 6.4 2.8
-11.8 -13 6.7 2.5 6.7 2.6 6.7 2.7 6.7 2.7 6.7 2.7 6.5 2.7
-9.8 -11 7.0 2.6 7.0 2.7 7.0 2.7 7.0 2.8 7.0 2.8 6.5 2.5
-9.5 -10 7.2 2.6 7.2 2.7 7.2 2.8 7.2 2.8 7.0 2.7 6.5 2.4
-8.5 -9.1
7.4 2.7 6.8 2.7 7.3 2.8 7.2 2.7 7.0 2.6 6.5 2.4
-7 -7.6 7.6 2.7 7.6 2.8 7.4 2.7 7.2 2.6 7.0 2.5 6.5 2.3
-5 -5.6 8.0 2.8 7.9 2.7 7.4 2.5 7.2 2.4 7.0 2.3 6.5 2.1
-3 -3.7 8.4 2.8 7.9 2.6 7.4 2.4 7.2 2.3 7.0 2.2 6.5 2.0
0 -0.7 8.4 2.5 7.9 2.3 7.4 2.2 7.2 2.1 7.0 2.0 6.5 1.8
3 2.2 8.4 2.3 7.9 2.1 7.4 2.0 7.2 1.9 7.0 1.8 6.5 1.7
5 4.1 8.4 2.1 7.9 2.0 7.4 1.9 7.2 1.8 7.0 1.7 6.5 1.6
7 6 8.4 2.0 7.9 1.9 7.4 1.8 7.2 1.7 7.0 1.6 6.5 1.5
9 7.9 8.4 1.9 7.9 1.8 7.4 1.6 7.2 1.6 7.0 1.6 6.5 1.4
11 9.8 8.4 1.8 7.9 1.7 7.4
1.6 7.2 1.5 7.0 1.5 6.5 1.3
13 11.8 8.4 1.7 7.9 1.6 7.4 1.5 7.2 1.4 7.0 1.4 6.5 1.3
15 13.7 8.4 1.6 7.9 1.5 7.4 1.4 7.2 1.3 7.0 1.3 6.5 1.2
