Chigo CHV Mini Series - Page 50

CHV Mini VRF 50/60Hz
201908 49
Part 2 - Outdoor Units
Combination (%)
(Capacity index)
Outdoor Air
temperature
(
°
C DB)
Indoor temperature(
°
C WB)
16 18 20 21 22 24
TC PI TC PI TC PI TC PI TC PI TC PI
°
C DB
°
C WB
kW kW kW kW kW kW kW kW kW kW kW kW
70%
-19.8 -20 5.8 2.5 5.8 2.6 5.8 2.7 5.8 2.7 5.8 2.7 5.7 2.7
-18.8 -19 5.9 2.5 5.9 2.6 5.9 2.7 5.9 2.7 5.9 2.7 5.7 2.6
-16.7 -17 6.1 2.6 6.1 2.7 6.1 2.7 6.1 2.8 6.1 2.4 5.7 2.5
-13.7 -15 6.4 2.6 6.4 2.7 6.4 2.8 6.3 2.7 6.1 2.6 5.7 2.4
-11.8 -13 6.7 2.7 6.7 2.8 6.5 2.7 6.3 2.6 6.1 2.4 5.7 2.3
-9.8 -11 7.0 2.7 6.9 2.7 6.5 2.5 6.3 2.4 6.1 2.3 5.7 2.1
-9.5 -10 7.2 2.8 6.9 2.6 6.5 2.4 6.3 2.4 6.1 2.3 5.7 2.1
-8.5 -9.1 7.3 2.8 6.9 2.6 6.5 2.4 6.3 2.3 6.1 2.2 5.7 2.0
-7 -7.6 7.3
2.6 6.9 2.4 6.5 2.3 6.3 2.2 6.1 2.1 5.7 2.0
-5 -5.6 7.3 2.5 6.9 2.3 6.5 2.1 6.3 2.0 6.1 2.4 5.7 1.8
-3 -3.7 7.3 2.3 6.9 2.2 6.5 2.0 6.3 2.0 6.1 1.9 5.7 1.7
0 -0.7 7.3 2.1 6.9 2.0 6.5 1.9 6.3 1.8 6.1 1.7 5.7 1.6
3 2.2 7.3 2.0 6.9 1.8 6.5 1.7 6.3 1.6 6.1 1.6 5.7 1.5
5 4.1 7.3 1.8 6.9 1.7 6.5 1.6 6.3 1.6 6.1 1.5 5.7 1.4
7 6 7.3 1.7 6.9 1.6 6.5 1.5 6.3 1.5 6.1 1.4 5.7 1.3
9 7.9 7.3 1.6 6.9 1.6 6.5 1.4 6.3 1.4 6.1 1.3 5.7 1.2
11 9.8 7.3 1.6 6.9 1.5 6.5 1.4 6.3 1.3 6.1 1.3 5.7 1.2
13 11.8 7.3 1.5 6.9 1.4 6.5 1.3 6.3
1.2 6.1 1.2 5.7 1.1
15 13.7 7.3 1.4 6.9 1.3 6.5 1.2 6.3 1.2 6.1 1.2 5.7 1.1
60%
-19.8 -20 5.8 2.7 5.8 2.8 5.6 2.6 5.4 2.5 5.2 2.4 4.9 2.2
-18.8 -19 5.9 2.7 5.9 2.8 5.6 2.6 5.4 2.5 5.2 2.4 4.9 2.2
-16.7 -17 6.1 2.8 5.9 2.7 5.6 2.4 5.4 2.4 5.2 2.3 4.9 2.1
-13.7 -15 6.3 2.7 5.9 2.5 5.6 2.3 5.4 2.3 5.2 2.2 4.9 2.0
-11.8 -13 6.3 2.6 5.9 2.4 5.6 2.2 5.4 2.1 5.2 2.0 4.9 1.9
-9.8 -11 6.3 2.4 5.9 2.3 5.6 2.1 5.4 2.0 5.2 2.0 4.9 1.8
-9.5 -10 6.3 2.4 5.9 2.2 5.6 2.0 5.4 2.0 5.2 1.9 4.9 1.7
-8.5 -9.1 6.3 2.3 5.9 2.1 5.6 2.0 5.4 1.9
5.2 1.8 4.9 1.7
-7 -7.6 6.3 2.2 5.9 2.0 5.6 1.9 5.4 1.8 5.2 1.8 4.9 1.6
-5 -5.6 6.3 2.0 5.9 1.9 5.6 1.8 5.4 1.7 5.2 1.6 4.9 1.6
-3 -3.7 6.3 2.0 5.9 1.8 5.6 1.7 5.4 1.6 5.2 1.6 4.9 1.5
0 -0.7 6.3 1.8 5.9 1.6 5.6 1.6 5.4 1.5 5.2 1.5 4.9 1.3
3 2.2 6.3 1.6 5.9 1.5 5.6 1.4 5.4 1.4 5.2 1.3 4.9 1.2
5 4.1 6.3 1.6 5.9 1.5 5.6 1.3 5.4 1.3 5.2 1.2 4.9 1.2
7 6 6.3 1.5 5.9 1.4 5.6 1.3 5.4 1.2 5.2 1.2 4.9 1.1
9 7.9 6.3 1.4 5.9 1.3 5.6 1.2 5.4 1.2 5.2 1.2 4.9 1.1
11 9.8 6.3 1.3 5.9 1.2 5.6 1.2 5.4 1.1 5.2 1.1 4.9 1.0
13
11.8 6.3 1.2 5.9 1.2 5.6 1.1 5.4 1.1 5.2 1.0 4.9 1.0
15 13.7 6.3 1.2 5.9 1.1 5.6 1.1 5.4 1.0 5.2 1.0 4.9 0.9
50%
-19.8 -20 5.2 2.4 4.9 2.3 4.7 2.1 4.5 2.0 4.3 2.0 4.0 1.8
-18.8 -19 5.2 2.4 4.9 2.2 4.7 2.1 4.5 2.0 4.3 1.9 4.0 1.8
-16.7 -17 5.2 2.3 4.9 2.1 4.7 2.0 4.5 1.9 4.3 1.8 4.0 1.7
-13.7 -15 5.2 2.2 4.9 2.0 4.7 1.9 4.5 1.8 4.3 1.7 4.0 1.6
-11.8 -13 5.2 2.0 4.9 1.9 4.7 1.8 4.5 1.7 4.3 1.6 4.0 1.6
-9.8 -11 5.2 2.0 4.9 1.8 4.7 1.7 4.5 1.6 4.3 1.6 4.0 1.5
-9.5 -10 5.2 1.9 4.9 1.8 4.7 1.6 4.5 1.6 4.3 1.6 4.0 1.4
-8.5 -9.1
5.2 1.9 4.9 1.7 4.7 1.6 4.5 1.6 4.3 1.5 4.0 1.4
-7 -7.6 5.2 1.8 4.9 1.6 4.7 1.6 4.5 1.5 4.3 1.4 4.0 1.3
-5 -5.6 5.2 1.7 4.9 1.6 4.7 1.5 4.5 1.4 4.3 1.4 4.0 1.2
-3 -3.7 5.2 1.6 4.9 1.5 4.7 1.4 4.5 1.3 4.3 1.3 4.0 1.2
0 -0.7 5.2 1.5 4.9 1.4 4.7 1.3 4.5 1.2 4.3 1.2 4.0 1.1
3 2.2 5.2 1.3 4.9 1.2 4.7 1.2 4.5 1.2 4.3 1.1 4.0 1.0
5 4.1 5.2 1.3 4.9 1.2 4.7 1.1 4.5 1.1 4.3 1.1 4.0 1.0
7 6 5.2 1.2 4.9 1.2 4.7 1.1 4.5 1.0 4.3 1.0 4.0 0.9
9 7.9 5.2 1.2 4.9 1.1 4.7 1.0 4.5 1.0 4.3 0.9 4.0 0.9
11 9.8 5.2 1.1 4.9 1.0 4.7
1.0 4.5 0.9 4.3 0.9 4.0 0.8
13 11.8 5.2 1.0 4.9 1.0 4.7 0.9 4.5 0.9 4.3 0.8 4.0 0.8
15 13.7 5.2 1.0 4.9 0.9 4.7 0.9 4.5 0.8 4.3 0.8 4.0 0.8
