Multi-Channel Sync Hipot Tester 19020/19020-4/19021/19022/19022-4
Quick Start Guide
(8) Data Entry Keys/Program Keys
0 . ～ 9:
They are numeric/character keys for inputting test
parameter data (value or English letters.)
ENTER:
It is the input confirmation key for setting test
parameters.
CLR:
It is the cancel key for clearing the inputted test
parameters when error occurs and entering the new
data again.
(9) Function Keys:
Different function key descriptions will appear in
different screen and the mapping function keys are
at the right of LCD. If the description is blank, it
indicates the mapping function key is invalid.
(10) Indicators:
DANGER LED:
It is the indicator of test status. When on it means
the Tester is performing test when on. Do not
touch the test terminals as they may contain high
voltage output.
PASS LED: It is the indicator for pass items. CH1~CH10
indicators stand for the test results of CH1~CH10.
The rectangular PASS LED is on only when the test
results of CH1~CH10 are all good.
FAIL LED: It is the indicator for fail items. CH1~CH10
indicators stand for the test results of CH1~CH10.
The rectangular FAIL LED is on when one of the
CH1~CH10 test results is bad and will keep on until
STOP is pressed.
The indicator shows the test result in the channel
numbers specified by the model, for instance, the
19020 shows the test result of CH1~CH10 and 19020-4
shows the test result of CH1~CH4.
9
