Chromalox MicroTherm CMX Series User Manual

User Instructions
TM
Ordering Information
CMX-250-4 4.5 240 13.6
CMX-250-4 4.5 480 6.8
CMX-250-9 9 240 24.5
CMX-250-9 9 480 12.2
CMX-250-12 12 240 31.7
CMX-250-12 12 480 15.8
CMX-250-18 18 240 46.1
CMX-250-18 18 480 23.1
CMX-250-24 24 240 60.5
CMX-250-24 24 480 30.3
CMX-250-4C 4.5 240 13.6
CMX-250-4C 4.5 480 6.8
CMX-250-9C 9 240 24.5
CMX-250-9C 9 480 12.2
CMX-250-12C 12 240 31.7
CMX-250-12C 12 480 15.8
CMX-250-18C 18 240 46.1
CMX-250-18C 18 480 23.1
CMX-250-24C 24 240 60.5
CMX-250-24C 24 480 30.3
• All voltages are 3 phase. 120V control transformer provided with each unit for control power.
-C: Suffi x indicates 3.8 sq. ft. heat exchanger for cooling. All systems equipped with 30 GPM 20 psi. TDH pump standard.
Optional Pump fl ows up to 80 GPM and 70 psi. TDH available.
• For low pressure applications - “250” in the model number is replaced by - “180”. Pressure switch is not provided.
