FUSES
WARNING!
• When replacing a blown fuse, always use an appropriate replacement fuse with the same
amp rating as the original fuse. Never replace a fuse with another fuse of higher amp rating.
Never replace a blown fuse with metal wires or any other material. Failure to use proper
fuses may result in serious personal injury, fire and/or property damage.
• Before replacing a fuse, make sure that the ignition is off and that all the other services are
switched off and/or disengaged.
• If the replaced fuse blows again, contact an authorized dealer.
•
If a general protection fuse for safety systems (air bag system, braking system), power unit
systems (engine system, gearbox system) or steering system blows, contact an authorized dealer.
Underhood Fuses
The Power Distribution Center is located in the engine compartment near the battery. This
center contains cartridge fuses, mini-fuses, micro-fuses, circuit breakers and relays. A label that
identifies each component is printed on the inside of the cover.
Cavity Cartridge Fuse Blade Fuse Description
F06 – – Not Used
F07 – 25 Amp Clear Ignition Coil/Fuel Injector
F08 – – Not Used
F09 – 25 Amp Clear Amplifier/ANC
F10 – – Not Used
F11 – – Not Used
F12 – 5 Amp Tan Battery Sensor (IBS)
F13 – – Not Used
F14 – 10 Amp Red ECM
F15 40 Amp Green – Power Locks
F16 – 20 Amp Yellow ECM
F17 30 Amp Pink – Starter
F18 40 Amp Green –
CBC Feed #4 (Exterior Lights #1)
F19 25 Amp Clear –
2nd Row Folding Seats
Solenoid LT
F20 – 10 Amp Red A/C Compressor Clutch
F21 25 Amp Clear –
2nd Row Folding Seat
Solenoid RT
F22 – – Not Used
F23 – – Not used
F24 – 20 Amp Yellow RR Wiper
MAINTAINING YOUR VEHICLE
219
