Cavity Cartridge Fuse Blade Fuse Description
F25B – 10 Amp Red
LT RR Door/RT RR Release
Module/Active Grill Shutter/
Power Mirror
F26 40 Amp Green – Front HVAC Blower Motor
F27 25 Amp Clear – RR Slide Door Module
F28 – 10 Amp Red
Diagnostic Port/ USB Port/
AUX Port/ Video USB Port
F29 – – Not Used
F30 – 15 Amp Blue Media Hub 1, 2/ Power Lumbar
F31 – – Not Used
F32 20 Amp Blue – ECM
F33 30 Amp Pink – Power Liftgate Module
F34 25 Amp Clear – RR Door Node
F35 25 Amp Clear – Sunroof Control Module
F36 – – Not Used
F37 40 Amp Green –
CBC Feed #4
(Exterior Lighting #2)
F38 60 Amp Yellow – Vacuum Cleaner
F39 25 Amp Clear – HVAC Blower Motor
F40 – – Not Used
F41 – – Not Used
F42 30 Amp Pink – Folding Seat Module
F43 – 20 Amp Yellow Fuel Pump Motor
F44 30 Amp Pink – CBC Feed #1 (Interior Lights)
F45 30 Amp Pink – Power Inverter
F46 30 Amp Pink – Driver Door Module
F47 30 Amp Pink – Passenger Door Module
F48 – – Not Used
F49 25 Amp Clear – RR Sliding Door Module
F50 25 Amp Clear – RR Door Module
F51 30 Amp Pink – Front Wiper
F52 30 Amp Pink – Brake Vacuum Pump
F53 – – Not Used
F54 40 Amp Green – ESP-ECU And Valves
F55 – 15 Amp Blue
Keyless Ignition System/DVD/
Voice Recognition Module
F56 – 10 Amp Red
Front and Rear HVAC Control
Module/ESP/ESC
F57 – – Not Used
F58 – – Not Used
