Chrysler 2017 Pacifica - Page 223

Cavity Cartridge Fuse Blade Fuse Description
F59 30 Amp Pink –
7 Way Connector Receptacle —
If Equipped
F60 – 20 Amp Yellow Rear Cargo APO
F61 – 20 Amp Yellow
Trailer Tow Right Stop/Turn —
If Equipped
F62 – – Not Used
F63 – 20 Amp Yellow
Trailer Tow Left Stop/Turn —
If Equipped
F64 – 15 Amp Blue RT HID Headlamp
F65 – – Not Used
F66 – 15 Amp Blue Instrument Panel Cluster (IPC)
F67 – 10 Amp Red
In Vehicle Temperature Sensor/
Humidity Sensor/Drivers Assist
System Module (DASM)/Park
Assist (PAM) – If Equipped
F68 – – Not Used
F69 – – Not Used
F70 – – Not Used
F71 – 20 Amp Yellow Horn
F72 – 10 Amp Red Heated Mirrors – If Equipped
F73 30 Amp Pink – Rear Defroster (EBL)
F74 20 Amp Blue – Trailer Tow Backup
F75 – 5 Amp Tan Overhead Console / RR ISC
F76 – 20 Amp Yellow Uconnect/DCSD/Telematics
F77 – 10 Amp Red
RR Entertainment Screen 1 And
2/ Media Screen 1 And 2/ 3rd
Row Row USB Charge Only/
2nd Row YSB Charge Only/
Sunroof/Rainsensor/CRVMM/
F78 – 15 Amp Blue Instrument Cluster/E-Shifter
F79 – 10 Amp Red
ICS/Front And Rear
HVAC/ SCCM/ EPB
F80 – – Not Used
F81 – – Not Used
F82 – – Not Used
F83 20 Amp Blue – TT Park Lights — If Equipped
F84 40 Amp Green – ESP Motor Pump
F85 – 20 Amp Yellow Cigar Lighter
F86 – – Not Used
F87 – – Not Used
F88 – 20 Amp Yellow Front Heated Seats
F89 – 20 Amp Yellow Rear Heated Seats
